Overview
It preserves critical user programs and data during unexpected power interruptions.
Moreover, its smart monitoring capability improves visibility into battery health and lifecycle status.
Designed for industrial automation environments, it supports long-term system reliability and data integrity.
Therefore, engineers rely on this module to protect controller configurations and operational parameters.
Its compact design integrates easily within compatible GE rack-based systems.
Specification
| Category | Parameter | Specification |
|---|---|---|
| General Information | Model Number | IC695ACC302 |
| Product Type | Auxiliary Smart Battery Module | |
| Function | Memory backup and battery health monitoring | |
| Compatible Platforms | GE Series 90-30 PLC and Rx3i PACSystems (system dependent) | |
| Battery Details | Battery Type | Lithium-based industrial-grade battery |
| Nominal Voltage | 3.6 V DC | |
| Battery Chemistry | Lithium Thionyl Chloride (typical) | |
| Capacity | Designed to maintain memory backup for rated duration (system dependent) | |
| Replacement | Field-replaceable battery module | |
| Backup Performance | Data Retention Function | Holds RAM/data during main power loss events |
| Retention Duration | Hours to days depending on system and load | |
| Activation Condition | Automatic on loss of main power | |
| Smart Monitoring | Reports battery condition to controller diagnostics | |
| Electrical Characteristics | Interface | Direct module connection to controller backplane |
| Current Draw | Minimal standby current for battery monitoring | |
| Isolation | Isolation designed for control system compatibility | |
| Indicators & Diagnostics | Status Feedback | System-level battery and module status via PLC diagnostics |
| Diagnostic Outputs | Alerts for low battery or end-of-life conditions | |
| Environmental Specifications | Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | –40°C to 85°C (–40°F to 185°F) | |
| Relative Humidity | 5–95% non-condensing | |
| Shock & Vibration | Designed for industrial control panel environments | |
| Mechanical Characteristics | Form Factor | Compact auxiliary module |
| Mounting | Direct mounting within compatible rack systems | |
| Dimensions | Standard module width for Series 90-30/Rx3i slots | |
| Weight | Lightweight for easy installation | |
| Compliance & Safety | Designed For | Industrial automation backup applications |
| Certifications | CE and UL (system dependent) | |
| Safety Features | Internal protection mechanisms for safe battery use |
FAQ
A1: It provides backup power to retain controller memory during power loss.
Q2: Does the module include battery health monitoring?
A2: Yes, it features smart diagnostics for monitoring battery condition.
Q3: Which systems are compatible with this battery module?
A3: It supports compatible GE Series 90-30 and Rx3i control platforms.
Q4: Can the battery be replaced in the field?
A4: Yes, technicians can replace the module without complex system modifications.
Q5: Why is a smart battery module important in PLC systems?
A5: It protects user programs and configuration data during unexpected power interruptions.
