Specification
| Parameter | Details |
|---|---|
| Brand | General Electric (GE) |
| Model | IC694MDL753 |
| Series | Rx3i PacSystem |
| Module Type | Digital Output |
| Number of Channels | 16 DC outputs |
| Output Voltage | 24 VDC nominal |
| Output Current per Channel | 0.5 A |
| Output Type | Sinking (NPN) / sourcing compatible |
| Isolation | Optical isolation per channel |
| Switching Speed | Typical 1 ms response time |
| Status Indicators | LED per output channel |
| Mounting | DIN rail or Rx3i PAC backplane |
| Backplane Current | 350 mA maximum from backplane at 5 VDC |
| Power Dissipation | 5 W typical under full load |
| Operating Temperature | 0–60°C (32–140°F) |
| Storage Temperature | -40–85°C (-40–185°F) |
| Humidity | 5–95% non-condensing |
| Vibration | 5–8.4 Hz: 3.5 mm, 8.4–150 Hz: 1.0 g |
| Shock | 10 g, 11 ms half-sine |
| Communication Interface | Rx3i PAC backplane compatible |
| Diagnostics | Individual channel monitoring, fault detection via PAC controller |
| Compliance / Certifications | CE, UL listed, RoHS compliant |
| Dimensions (HxWxD) | 121 mm × 32 mm × 103 mm |
| Weight | 0.28 kg |
FAQ
Q1: What type of outputs does the IC694MDL753 module provide?
A1: The module provides 16 DC digital outputs suitable for standard industrial automation signals.
Q2: Can it be integrated with existing Rx3i PAC controllers?
A2: Yes, it is fully compatible with Rx3i PacSystem controllers and backplanes.
Q3: What is the maximum current per channel?
A3: Each channel supports up to 0.5 A DC output.
Q4: Does the module support diagnostics?
A4: Yes, built-in LEDs and monitoring features allow real-time status and fault detection.
Q5: What industrial applications are best suited for this module?
A5: It is ideal for controlling
