Overview
It delivers stable and reliable power to multiple I/O modules and PLC components in industrial automation.
Moreover, its compact design allows easy integration into existing control racks while maintaining high efficiency.
Engineers rely on this module to support complex process automation systems with minimal downtime.
Specification
| Parameter | Specification |
|---|---|
| Brand | GE |
| Model | IC694PWR331 |
| Module Type | High-Capacity 24 VDC Power Supply |
| Output Voltage | 24 VDC nominal |
| Maximum Output Current | 10 A continuous, 15 A peak |
| Power Capacity | 240 W continuous |
| Input Voltage | 100–240 VAC, 50/60 Hz |
| Efficiency | >85% typical at full load |
| Ripple & Noise | <50 mV peak-to-peak |
| Isolation | Input-to-output and output-to-chassis isolation |
| Protection Features | Overload, short-circuit, overvoltage, thermal shutdown |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 70°C |
| Relative Humidity | 5–95%, non-condensing |
| Mounting | DIN rail or standard PacSystem rack mount |
| Dimensions | 60 mm W × 150 mm H × 150 mm D |
| Certifications | UL, CE, CSA compliant |
| Application Scope | PLCs, Rx3i PacSystem I/O modules, process automation, industrial control systems |
FAQ
Q1: What is the maximum output current of IC694PWR331?
It provides up to 10 A continuous and 15 A peak output current.
Q2: Can this module support multiple I/O modules simultaneously?
Yes, it delivers reliable power to multiple PLC and I/O modules in the Rx3i PacSystem.
Q3: What protection features are included?
The module includes overload, short-circuit, overvoltage, and thermal protection.
Q4: What is the operating temperature range?
The IC694PWR331 operates between 0°C and 55°C.
Q5: Is the module easy to install in existing racks?
Yes, it supports DIN rail and standard PacSystem rack mounting.
