Overview
It converts PLC commands into precise on/off signals for actuators, relays, and indicator devices.
Moreover, the module ensures consistent output performance even in harsh industrial environments.
Engineers use this unit to manage digital actuators in automated production lines efficiently.
Therefore, it supports high-speed switching and accurate process coordination.
In addition, the module’s direct backplane connection enables seamless integration with Rx3i CPUs.
The IC694MDL732 is engineered for long-term reliability, offering robust protection against voltage spikes and short circuits.
As a result, it reduces maintenance interventions and improves overall system uptime.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | GE Intelligent Platforms |
| Product Series | Rx3i PACSystems |
| Model Number | IC694MDL732 |
| Module Type | Digital Output Module |
| Number of Channels | 16 discrete DC outputs |
| Output Voltage | 5–60 VDC nominal |
| Output Current | Maximum 0.5 A per channel |
| Switching Type | DC on/off, high-speed |
| Isolation | Channel-to-channel and backplane isolation |
| Diagnostics | Status LEDs and PLC-based fault reporting |
| Backplane Interface | Rx3i PACSystems backplane |
| Power Requirements | Powered via rack backplane |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Mechanical Construction | Industrial-grade module housing |
| Mounting | Rx3i rack-compatible slot |
| Compliance | Meets industrial automation electrical standards |
FAQ
Q1: How many outputs does the IC694MDL732 provide?
A1: The module provides 16 discrete DC output channels.
Q2: What voltage and current ranges are supported?
A2: It supports 5–60 VDC with a maximum current of 0.5 A per channel.
Q3: Can the module detect output faults?
A3: Yes, built-in diagnostics and status LEDs provide fault detection.
Q4: Is it compatible with Rx3i PACSystems racks?
A4: Yes, it integrates directly into Rx3i backplane slots.
Q5: Can it operate in industrial environments?
A5: Yes, it supports standard temperature and humidity ranges for industrial automation.
