Overview
It ensures consistent voltage and current levels for CPUs, I/O modules, and communication devices.
Moreover, this power supply supports demanding industrial environments with minimal voltage ripple.
Engineers use the IC697PWR713 to centralize power distribution within high-density automation racks.
Therefore, it reduces wiring complexity while maintaining dependable operation across all connected modules.
In addition, integrated protection circuitry safeguards the system against overloads and short circuits.
The module is designed for long-term industrial performance, offering high efficiency and low heat generation.
As a result, it contributes to overall system reliability and reduces maintenance requirements.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | GE Intelligent Platforms |
| Product Series | Series 90-70 PLC |
| Model Number | IC697PWR713 |
| Module Type | DC Power Supply Module |
| Output Voltage | 5 VDC, 24 VDC (typical outputs for rack modules) |
| Output Current | Maximum rated current per rack specification |
| Load Regulation | Maintains stable voltage under varying load conditions |
| Input Voltage | 120/240 VAC, 50/60 Hz standard industrial supply |
| Power Consumption | Dependent on connected modules and load |
| Efficiency | High efficiency for continuous operation |
| Ripple & Noise | Low output ripple to ensure stable module operation |
| Protection Features | Overvoltage, overcurrent, short-circuit protection |
| Monitoring | LEDs for operational and fault status |
| Redundancy Support | Yes, parallel operation supported |
| Mounting Method | Front-panel rack-mounted within 90-70 chassis |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Mechanical Construction | Industrial-grade metal housing |
| Serviceability | Front-accessible for inspection and replacement |
FAQ
Q1: What is the primary function of the IC697PWR713?
A1: It provides stable DC power to GE Series 90-70 PLC racks.
Q2: Can this module operate in redundant configurations?
A2: Yes, it supports parallel operation for redundancy in critical systems.
Q3: Does the module include fault diagnostics?
A3: Yes, it features LED indicators for operational and fault status monitoring.
Q4: What environments can it operate in?
A4: It supports standard industrial temperature and humidity ranges.
Q5: Is the IC697PWR713 easy to install and replace?
A5: Yes, its front-panel design allows straightforward installation and maintenance.
