Overview
It enables reliable backplane communication between local and expansion racks in PLC systems.
Moreover, the cable maintains high-speed data transfer across extended system layouts without signal degradation.
Engineers use it to expand I/O capacity while preserving deterministic communication performance.
Therefore, complex automation architectures scale efficiently without sacrificing reliability.
The IC693CBL300 supports flexible cabinet layouts and multi-rack installations in industrial environments.
In addition, its rugged construction ensures consistent operation under vibration and electrical noise conditions.
Specification
| Parameter | Specification |
|---|---|
| Model Number | IC693CBL300 |
| Manufacturer | GE |
| Device Type | I/O Bus Expansion Cable |
| Compatible Series | Series 90-30 PLC |
| Function | Connects CPU baseplate to expansion or remote baseplate |
| Cable Length | 3 feet (0.9 meters) standard length |
| Connector Type | High-density keyed expansion connectors |
| Shielding | Overall shielded cable for EMI protection |
| Signal Type | Backplane bus communication signals |
| Maximum Expansion Distance | Up to 15 meters total with supported expansion cables |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | –40°C to +85°C (–40°F to 185°F) |
| Installation | Panel-mounted racks and enclosed cabinets |
| Compliance | UL recognized, CE compliant |
| Applications | Multi-rack PLC systems, distributed I/O layouts, panel expansions |
FAQ
A1: It connects Series 90-30 CPU baseplates to expansion racks for extended I/O capacity.
Q2: What is the standard cable length?
A2: The standard length is 3 feet, approximately 0.9 meters.
Q3: Can multiple expansion cables be used in one system?
A3: Yes, supported configurations allow up to 15 meters total expansion distance.
Q4: Is the cable shielded for industrial environments?
A4: Yes, it features overall shielding to reduce electromagnetic interference.
Q5: Does it require special configuration after installation?
A5: No additional configuration is required beyond standard Series 90-30 rack setup.
