Overview
It provides dedicated processing power for complex algorithms, data handling, and communication tasks.
Moreover, the module operates independently from the main CPU, reducing scan time impact.
Engineers can implement custom C applications, advanced calculations, and protocol conversions directly inside the PLC rack.
Therefore, high-performance automation systems achieve faster response and greater flexibility.
The IC697PCM711 integrates seamlessly into the Series 90-70 backplane architecture.
In addition, it supports advanced memory management and multitasking for demanding industrial environments.
Specification
| Parameter | Specification |
|---|---|
| Model Number | IC697PCM711 |
| Manufacturer | GE |
| Device Type | Programmable Coprocessor Module |
| Compatible Series | Series 90-70 PLC |
| Processor | 80486-class microprocessor |
| Programming Language | C language (user-developed applications) |
| Memory | 2 MB RAM (expandable depending on configuration) |
| Flash Storage | Non-volatile program storage supported |
| Communication Ports | 2 × RS-232/422/485 serial ports |
| Backplane Interface | High-speed shared memory interface |
| Power Supply | 5 V DC from PLC backplane |
| Power Consumption | Approx. 7 W typical |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | –40°C to +85°C (–40°F to 185°F) |
| Mounting | Series 90-70 rack installation |
| Diagnostics | LED status indicators, fault reporting to CPU |
| Applications | Protocol conversion, data logging, advanced computation, custom control algorithms |
| Certifications | UL, CE compliant |
FAQ
A1: It provides additional processing power for custom applications within Series 90-70 PLC systems.
Q2: Which programming language does the module support?
A2: It supports C programming for user-developed applications and advanced control functions.
Q3: How does it communicate with the PLC CPU?
A3: It uses a high-speed shared memory interface through the Series 90-70 backplane.
Q4: Can it handle protocol conversion tasks?
A4: Yes, it is commonly used for Modbus gateways and custom communication drivers.
Q5: Is it suitable for demanding industrial environments?
A5: Yes, it is designed for continuous operation in industrial automation systems.
