Overview
It provides high-speed data exchange between distributed I/O devices and central control processors.
Moreover, the module supports Factory Instrumentation Protocol (FIP) networks for reliable industrial communication.
Engineers gain precise control over network configuration, diagnostics, and device synchronization.
Therefore, complex automation systems maintain consistent performance across distributed architectures.
The IC693BEM341 integrates directly into the Series 90-30 backplane for seamless system expansion.
In addition, it reduces wiring complexity by consolidating communication over a single fieldbus network.
Specification
| Parameter | Specification |
|---|---|
| Model Number | IC693BEM341 |
| Manufacturer | GE |
| Device Type | FIP Controller Module |
| Compatible Series | Series 90-30 PLC |
| Communication Protocol | Factory Instrumentation Protocol (FIP) |
| Network Role | FIP Controller / Master |
| Data Transfer Rate | Up to 1 Mbps (network dependent) |
| Network Topology | Bus or distributed architecture |
| Backplane Interface | Series 90-30 rack compatible |
| Diagnostics | Network status LEDs and PLC-reported error codes |
| Isolation | Electrical isolation between network and backplane |
| Power Supply | 5 V DC from PLC backplane |
| Power Consumption | Typical 3 W |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | –20°C to +70°C (–4°F to 158°F) |
| Mounting | Backplane installation in Series 90-30 chassis |
| Applications | Distributed I/O control, process automation, manufacturing systems |
| Certifications | UL, CE compliant |
FAQ
A1: It acts as a FIP network controller for Series 90-30 PLC systems.
Q2: What communication protocol does it support?
A2: It supports the Factory Instrumentation Protocol (FIP) for deterministic industrial communication.
Q3: Can it be used in distributed automation systems?
A3: Yes, it enables communication between PLCs and distributed I/O devices across a FIP network.
Q4: How does it integrate into the PLC system?
A4: It installs directly into the Series 90-30 backplane rack.
Q5: Does the module provide diagnostic features?
A5: Yes, it offers LED indicators and PLC-reported fault diagnostics for network monitoring.
