Overview
Engineers frequently choose this module when control applications require both signal monitoring and actuator control within a single compact I/O device.
Moreover, the module combines analog inputs and outputs in one unit, which reduces cabinet space and simplifies system architecture.
Its 12-bit conversion resolution ensures stable analog measurement and control signals across demanding industrial environments.
Therefore, many system integrators install the IC200ALG430 module when building flexible automation systems using VersaMax PLC platforms.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric |
| Model Number | IC200ALG430 |
| Product Type | Mixed Analog Input / Output Module |
| Series | VersaMax Distributed I/O |
| Analog Input Channels | 4 channels |
| Analog Output Channels | 2 channels |
| Input Signal Types | Voltage or current depending on configuration |
| Output Signal Types | Voltage or current analog control signals |
| Analog Resolution | 12-bit A/D and D/A conversion |
| Input Measurement Range | Industrial analog signals such as 0–10 V or 4–20 mA |
| Output Control Range | Industrial voltage or current control outputs |
| Conversion Method | Integrated analog-to-digital and digital-to-analog conversion |
| Accuracy | High industrial measurement accuracy for process signals |
| Diagnostic Indicators | LED indicators for module power and operational status |
| Backplane Communication | VersaMax I/O backplane communication interface |
| Configuration | Configured through VersaMax PLC programming environment |
| Mounting Method | Installed on VersaMax I/O carrier or baseplate |
| System Compatibility | VersaMax PLC CPUs and distributed I/O systems |
| Power Supply | Powered directly through the VersaMax backplane |
| Operating Temperature | Suitable for industrial control cabinet environments |
| Storage Temperature | Industrial storage temperature range supported |
| Environmental Conditions | Designed for industrial environments with electrical noise |
| Typical Application Areas | Factory automation, process control, utilities, and machine automation |
FAQ
Q1: What type of module is the IC200ALG430?
The IC200ALG430 is a mixed analog I/O module that combines analog input monitoring and analog output control in one device.
Q2: How many analog channels does the module provide?
The module includes four analog input channels and two analog output channels for flexible industrial automation applications.
Q3: What resolution does the module use for analog signals?
The IC200ALG430 uses 12-bit analog conversion for both input measurement and output signal generation.
Q4: Which control systems support the IC200ALG430 module?
The module integrates with VersaMax PLC systems developed by General Electric for distributed automation architectures.
Q5: Where is the IC200ALG430 module commonly used?
Engineers install the module in manufacturing automation, water treatment facilities, energy systems, and machine control applications.
