Overview
Engineers choose this module when applications require precise control of actuators, valves, and process devices in real time.
Moreover, the module integrates directly with VersaMax PLC platforms, enabling flexible installation across machine panels and distributed control cabinets.
Its high-resolution output channels deliver stable analog signals, improving automation accuracy and process consistency.
Therefore, system integrators frequently deploy the IC200ALG320 module for scalable industrial control applications across manufacturing and process plants.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric |
| Model Number | IC200ALG320 |
| Product Type | Analog Output Module |
| Series | VersaMax Distributed I/O |
| Output Channels | 4 independent analog output channels |
| Output Signal Types | Current (4–20 mA), Voltage (0–10 V) |
| Resolution | High-resolution 12-bit digital-to-analog conversion |
| Accuracy | ±0.25% of full scale typical |
| Load Resistance | 0–500 Ω for current outputs, 0–10 kΩ for voltage outputs |
| Output Update Time | Fast response suitable for real-time process control |
| Isolation | Channel-to-system electrical isolation for signal integrity |
| Diagnostic Functions | Module status LEDs and PLC diagnostics |
| Communication Interface | VersaMax I/O backplane |
| Configuration Method | Configured via VersaMax PLC programming software |
| Mounting Method | Installed on VersaMax I/O baseplate or carrier |
| System Compatibility | VersaMax PLC CPUs and distributed I/O networks |
| Power Supply | Powered from VersaMax I/O backplane |
| Operating Temperature | Suitable for industrial control cabinet conditions |
| Storage Temperature | Standard industrial storage range |
| Relative Humidity | Non-condensing industrial environments |
| Mechanical Design | Compact modular design for distributed I/O systems |
| Typical Applications | Manufacturing automation, process control, utilities, energy, and machine control |
FAQ
Q1: What types of outputs does the IC200ALG320 module provide?
It provides both current (4–20 mA) and voltage (0–10 V) analog outputs for industrial control applications.
Q2: How many output channels does this module support?
The module supports four independent analog output channels, allowing simultaneous control of multiple field devices.
Q3: What resolution does the analog conversion provide?
The IC200ALG320 uses high-resolution 12-bit digital-to-analog conversion for precise process control.
Q4: Which systems are compatible with the IC200ALG320 module?
It integrates with VersaMax PLC CPUs and distributed I/O networks developed by General Electric.
Q5: Where is this module typically installed?
Engineers install it in control cabinets, distributed I/O stations, and machine panels within industrial automation environments.
