Overview
Specification
| Parameter | Specification |
|---|---|
| Model | IC200MDD840 |
| Module Type | VersaMax Mixed Module (Digital + Analog) |
| Digital Input | 8 channels, 24 VDC |
| Digital Output | 8 channels, 24 VDC, 0.5 A per channel |
| Analog Input | 4 channels, 0–10 V, 0–20 mA |
| Analog Output | 2 channels, 0–10 V, 0–20 mA |
| Input Resolution | 12-bit for analog channels |
| Output Resolution | 12-bit for analog channels |
| Communication | VersaMax backplane interface to CPU |
| Power Supply | 5 VDC ±5%, 0.8 A typical |
| Power Consumption | Approximately 5 W |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Mounting | DIN rail or panel mount |
| Dimensions | 122 mm (H) x 35 mm (W) x 112 mm (D) |
| Status Indicators | LEDs for RUN, ERROR, and I/O activity |
| Certifications | CE, UL Listed |
| Environmental Protection | Resistant to vibration, electrical noise, and industrial stress |
| Typical Applications | Factory automation, process control, packaging, material handling |
FAQ
It supports 8 digital inputs, 8 digital outputs, 4 analog inputs, and 2 analog outputs.
Q2: Can it integrate with VersaMax CPU modules?
Yes, it communicates seamlessly via the VersaMax backplane interface.
Q3: What is the operating temperature range?
The module operates reliably between 0°C to 60°C (32°F to 140°F).
Q4: How are module and I/O statuses indicated?
LEDs display RUN, ERROR, and channel activity for easy monitoring.
Q5: Is it suitable for harsh industrial environments?
Yes, it resists vibration, electrical noise, and standard industrial stresses.
