Overview
Engineers frequently choose this module when control systems require stable differential current inputs and high-resolution signal acquisition.
Moreover, the module integrates seamlessly with VersaMax I/O platforms, allowing scalable distributed control architectures across manufacturing environments.
Its 15-bit resolution ensures accurate process signal conversion, which helps operators monitor sensors and field devices with reliable precision.
This eight-channel differential input module processes standard industrial current signals while maintaining strong noise immunity in electrically harsh environments.
In addition, differential input architecture minimizes interference from ground loops and electromagnetic disturbances commonly found in industrial installations.
Therefore, control engineers often deploy the IC200ALG262 module in applications requiring consistent measurement accuracy and dependable long-term performance.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric |
| Model Number | IC200ALG262 |
| Product Type | Analog Input Module |
| Series | VersaMax Distributed I/O System |
| Input Channel Count | 8 independent differential analog input channels |
| Input Signal Type | Differential current input |
| Typical Input Range | 4–20 mA industrial current signals |
| Analog Resolution | 15-bit analog-to-digital conversion |
| Input Architecture | Differential measurement for improved noise rejection |
| Data Conversion Method | High-precision A/D conversion with digital filtering |
| Measurement Accuracy | High-accuracy acquisition suitable for process monitoring |
| Input Isolation | Channel-to-system electrical isolation for industrial safety |
| Noise Immunity | Differential inputs reduce electromagnetic interference and ground loop effects |
| Update Time | Fast scanning suitable for real-time industrial monitoring |
| Diagnostic Functions | Module status indicators and fault diagnostics through controller interface |
| LED Indicators | Power, module status, and I/O activity indicators |
| Backplane Communication | VersaMax high-speed backplane communication interface |
| Configuration Method | Configured through PLC programming software within VersaMax control systems |
| Mounting Method | Installed on VersaMax I/O carrier or baseplate |
| System Compatibility | Compatible with VersaMax PLC CPUs and remote I/O stations |
| Power Consumption | Powered directly from the VersaMax I/O backplane |
| Environmental Protection | Designed for industrial electrical environments |
| Operating Temperature | Suitable for standard industrial control cabinet environments |
| Storage Temperature | Industrial-grade storage conditions supported |
| Relative Humidity | Designed for non-condensing industrial humidity ranges |
| Mechanical Design | Compact modular design for high-density distributed I/O systems |
| Application Environment | Factory automation, process control, utilities, energy monitoring, and machine control |
FAQ
Q1: What type of signals does the IC200ALG262 module measure?
The module measures industrial current input signals using eight differential channels designed for stable and accurate analog acquisition.
Q2: Why does this module use differential input architecture?
Differential inputs reduce electrical noise and ground loop interference, which improves signal accuracy in complex industrial environments.
Q3: Which control systems support the IC200ALG262 module?
The module integrates with VersaMax PLC systems developed by General Electric and supports distributed industrial I/O architectures.
Q4: What resolution does the analog conversion provide?
The IC200ALG262 module provides 15-bit analog resolution, allowing precise measurement of industrial process signals and sensor outputs.
Q5: Where is this module typically installed?
Engineers typically install this module in VersaMax I/O stations inside machinery control cabinets, distributed control panels, or industrial automation enclosures.
