Overview
This module integrates seamlessly into HIMA safety systems, delivering dependable diagnostics and deterministic response behavior. In addition, its certified safety architecture ensures compliance with international functional safety standards.
Specification
| Parameter | Specification |
|---|---|
| Model | F3DIO20/802 |
| Product Name | F3 DIO 20/8 02 |
| Manufacturer | HIMA |
| Module Type | Safety Digital I/O Module |
| Digital Inputs | 20 safety-related digital inputs |
| Digital Outputs | 8 safety-related digital outputs |
| Output Type | Solid-state, safety switching |
| Rated Input Voltage | 24 V DC |
| Rated Output Voltage | 24 V DC |
| Input Signal Type | Dry contact or 24 V DC |
| Diagnostics | Line monitoring, short-circuit and wire-break detection |
| Response Time | Suitable for safety-critical applications |
| System Compatibility | HIMA F3 safety controllers |
| Mounting Method | Rack-based installation |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -20°C to +70°C |
| Safety Certification | SIL 3, IEC 61508 |
| Approvals | TÜV certified, CE compliant |
FAQ
A1: It provides safety-rated digital inputs and outputs for HIMA safety controller systems.
Q2: How many I/O channels does this module support?
A2: It supports 20 digital inputs and 8 digital outputs.
Q3: Is the F3DIO20/802 suitable for SIL 3 applications?
A3: Yes, the module is TÜV certified for SIL 3 according to IEC 61508.
Q4: What type of voltage does the module use?
A4: Both inputs and outputs operate at 24 V DC.
Q5: Can this module be used in emergency shutdown systems?
A5: Yes, it is commonly used in ESD, BMS, and other safety-critical systems.
Q6: Does the module support internal diagnostics?
A6: Yes, it includes continuous self-monitoring and line diagnostics.
