Overview
Specification
| Parameter | Specification |
|---|---|
| Product Type | Analog Input Module |
| Manufacturer | Rockwell Automation |
| Model Number | T9432 |
| Power Supply | 24 VDC nominal |
| Input Type | Analog signals (current and voltage ranges) |
| Number of Channels | Multiple channels (refer to datasheet for exact configuration) |
| Accuracy | ±0.1% of full scale (typical) |
| Response Time | 5 ms typical per channel |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | -40 °C to 85 °C |
| Humidity | 5–95% non-condensing |
| Communication | Triplex ICS network compatible |
| Mounting | Rack or panel installation |
| Dimensions | Standard module form factor |
| Certifications | IEC 61508, SIL-2/SIL-3 compliance |
| Special Features | Triplex architecture support, high-speed signal acquisition |
FAQ
A1: The module operates at 24 VDC nominal for analog signal acquisition.
Q2: How many analog channels does it support?
A2: It supports multiple channels; exact configuration depends on the system setup.
Q3: Can it integrate with Triplex ICS safety systems?
A3: Yes, it is fully compatible with ICS Triplex control and safety architectures.
Q4: What is the operating temperature range?
A4: The module operates reliably between 0 °C and 60 °C.
Q5: Does Rockwell provide technical support?
A5: Yes, detailed manuals and technical assistance are available for all installations.
