Overview
Specification
| Parameter | Specification |
|---|---|
| Model | F2DO801 |
| Product Code | F2 DO 8 01 |
| Manufacturer | HIMA |
| Module Type | Safety-Related Digital Output Module |
| Controller Family | HIMatrix F2 |
| Number of Outputs | 8 digital safety outputs |
| Output Type | Safety-rated switching outputs |
| Rated Output Voltage | 24 V DC |
| Maximum Output Current | Up to 0.5 A per channel |
| Safety Integrity Level | SIL 3 according to IEC 61508 |
| Diagnostics | Continuous channel and system diagnostics |
| Output Monitoring | Line monitoring and fault detection |
| Power Supply | 24 V DC |
| Internal Protection | Short-circuit and overload protection |
| Mounting Method | HIMatrix F2 system rack |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -20°C to +70°C |
| Environmental Compliance | CE marked, TÜV certified |
| Typical Load Types | Solenoid valves, relays, contactors |
FAQ
A1: It provides eight safety-rated digital outputs for controlling actuators in HIMatrix safety systems.Q2: Is the F2 DO 8 01 suitable for SIL 3 applications?
A2: Yes, the module is certified for SIL 3 according to IEC 61508 standards.
Q3: What type of loads can the outputs drive?
A3: The outputs can drive solenoid valves, relays, contactors, and other industrial actuators.
Q4: Does the module include diagnostic monitoring?
A4: Yes, it continuously monitors output channels and detects faults such as short circuits.
Q5: Which HIMatrix systems support this module?
A5: It is designed for integration within HIMatrix F2 safety controller systems.
Q6: What power supply does the F2DO801 require?
A6: The module operates using a standard 24 V DC industrial power supply.
