Overview
The ABB TK854V030, also cataloged as the TK854V030 Connection Cable, operates as a dedicated hardware component for signal and interface connection tasks within ABB System 800xA and AC 800M controller platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | TK854V030 (3BSE088466R1) |
| Brand | ABB |
| Dimensions | 3.0 m cable length |
| Operating Temp | -25 deg C to +70 deg C |
| Power Consumption | Passive cable assembly, no external power consumption |
| Product Type | Interface / Connection Cable |
| Cable Length | 3.0 m |
| Connector Type | Pre-assembled ABB system connectors |
| Cable Construction | Shielded copper conductor cable |
| Shielding | Screened design for electromagnetic interference reduction |
| System Compatibility | ABB System 800xA, Compact Products 800, AC 800M Controllers |
| Storage Temperature | -40 deg C to +85 deg C |
| Environmental Compliance | RoHS compliant |
ABB Industrial Control Interface Connectivity
The ABB TK854V030 supports physical signal transmission between compatible ABB automation hardware assemblies. The cable uses factory-installed connectors to maintain correct interface alignment and reduce wiring errors during system installation.
Furthermore, ABB industrial control platforms require controlled signal routing between modules, termination units, and controller interfaces. The TK854V030 provides a fixed-length connection path with shielded construction to reduce external electrical noise influence on connected circuits.
For ABB PLC and DCS configurations, cable selection affects communication stability across backplane and module interface structures. Therefore, the TK854V030 follows ABB connection standards for System 800xA and AC 800M hardware integration.
Frequently Asked Questions
Q: Is the ABB TK854V030 an active communication device?
A: No. The TK854V030 is a passive connection cable assembly. It does not contain processing electronics, firmware, or external power requirements.
Q: Can the TK854V030 replace other ABB cables with the same length?
A: Replacement depends on connector type, system interface requirements, and ABB hardware compatibility. The cable should match the specified ABB part number and connection design.
Q: What installation practice is recommended for the TK854V030 shielded cable?
A: Install the cable away from high-current power wiring where possible. Connect shielding according to the grounding method defined for the ABB control system installation.
Field Installation Guidelines
- Verify the cable part number before installation to confirm compatibility with the target ABB System 800xA or AC 800M hardware.
- Inspect connectors for mechanical damage before connection.
- Install the cable with suitable bending radius to prevent conductor or shield damage.
- Separate the cable routing from high-voltage and high-frequency interference sources.
- Connect the cable shield according to the site grounding specification.
- Secure the cable to prevent vibration-related mechanical stress on connectors.
