Overview
The IMDSO04 is a precision output module designed by ABB Bailey for Infi 90 and Net 90 distributed control systems. Furthermore, it actively manages multiple output channels, ensuring accurate and timely signal delivery to field devices. By supporting various I/O configurations, the module enhances operational efficiency and maintains system integrity in demanding industrial environments.
Specification
| Attribute | Value |
| Power Requirements | Voltage +5 VDC(±5%) |
| Current Consumption 135 mA(typical)200 mA(maximum) | |
| Dissipation (logic only) 750 mW(typical)1.2 W(maximum) | |
| Outputs | Load Voltage 24 VDC |
| Load Current(maximum) 250 mA | |
| Off Leakage Current(maximum) 10 μA@70℃(158°F) | |
| On Voltage Drop(maximum) 2.4V@70℃(158°F) | |
| Current Consumption 150 mA(typical),250 mA(maximum) | |
| Isolation | 300Vrms between output and logic circuitry and output to output.CSA approved for 300 V isolation. |
| Surge Withstanding Capability | Meets ANSI/IEEE C37.90A-1974 “Guide for Surge Withstanding Capability Test”. |
| Mounting | Occupies one slot in a standard Infi 90 module mounting unit |
| Environmental | Ambient Temperature 0°to 70℃(32 to 158°F) |
| Relative Humidity 0 to 95%up to 55℃(131°F)(non-condensing)0 to 45%at 70C(158°F)(non-condensing) | |
| Atmospheric Pressure Sea level to 3 km(1.86 miles) | |
| Air Quality Non-corrosive | |
| Certification | CSA certified as process control equipment in an ordinary(non-hazardous)location. |
