Overview
Specification
| Parameter | Specification |
|---|---|
| Model | Triconex 3604E |
| Type | Digital Output Module |
| Rated Voltage | 24VDC |
| Number of Points | 16 digital outputs |
| Redundancy | Triple Modular Redundant (TMR) |
| Output Type | Sourcing (current sourcing outputs) |
| Output Current | 0.5A per channel maximum |
| Isolation | Galvanically isolated outputs |
| Response Time | Typically <10ms |
| Indicators | Individual LEDs for each output |
| Mounting | Triconex I/O rack, hot-swappable |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | –40°C to 85°C |
| Humidity | 5–95% RH, non-condensing |
| Dimensions | Standard Triconex module size |
| Certifications | IEC 61508 SIL-3 / IEC 61511 compliant |
FAQ
A1: The module provides 16 digital output channels, each rated for 24VDC.Q2: Is the 3604E suitable for SIL-3 safety applications?
A2: Yes. It is IEC 61508 and IEC 61511 certified for SIL-3 safety compliance.
Q3: Can the module be replaced without shutting down the system?
A3: Yes. The hot-swappable design allows safe replacement while the system remains operational.
Q4: What type of redundancy does the module use?
A4: It operates within a Triple Modular Redundant (TMR) system for maximum reliability.
Q5: Are output statuses visible to operators?
A5: Yes. Individual LED indicators provide clear real-time status for each channel.
