Overview
Furthermore, its robust design withstands harsh industrial conditions, including electrical noise, temperature fluctuations, and vibration. Therefore, the UR7HH delivers stable performance while ensuring real-time relay status and event reporting. In addition, engineers benefit from easy installation, configuration, and maintenance, which optimizes overall system reliability.
Specification
| Parameter | Description / Value |
|---|---|
| Model | UR7HH |
| Module Type | Communications Module for GE UR Series Relays |
| Supported Protocols | Modbus RTU, DNP3, IEC 61850, Ethernet/IP (protocol depends on configuration) |
| Network Interfaces | 1 × RS-485 serial port, 1 × 10/100 Mbps Ethernet port |
| Data Rates | RS-485: up to 115.2 kbps; Ethernet: 10/100 Mbps full-duplex |
| Power Supply | 24 VDC ±10%; typical 2.5 W power consumption |
| Operating Temperature | -20°C to 70°C (-4°F to 158°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5–95% non-condensing |
| Isolation | 2 kV RMS isolation between power and communication ports |
| Mounting | DIN rail or panel mount |
| Status Indicators | LEDs for power, communication activity, and fault conditions |
| Communication Distance | RS-485: up to 1200 m; Ethernet: up to 100 m |
| Connectors | Screw terminals for RS-485; RJ45 for Ethernet |
| Shock & Vibration | Designed to withstand IEC 60068-2-6 and IEC 60068-2-27 testing |
| Compliance | CE, UL, and industry-standard certifications for electrical and EMC safety |
| Diagnostics | Built-in self-test, fault reporting, and status monitoring |
| Firmware Upgrade | Supports field firmware upgrades via Ethernet or serial interface |
FAQ
A1: The UR7HH is fully compatible with all UR series universal relays, ensuring seamless integration.
Q2: What communication protocols does the UR7HH support?
A2: It supports Modbus RTU, DNP3, IEC 61850, and Ethernet/IP for flexible network connectivity.
Q3: Can the module operate in harsh industrial environments?
A3: Yes, it operates reliably under temperature extremes, vibrations, and electrical noise conditions.
Q4: How is the UR7HH installed?
A4: It mounts easily on a DIN rail or panel, with straightforward wiring for power and data connections.
Q5: Does the module provide status and fault indicators?
A5: Yes, LED indicators display communication status, power presence, and fault conditions.
Q6: Can it integrate with SCADA systems?
A6: Absolutely, it connects to SCADA or DCS networks, enabling real-time monitoring and control.
