Overview
GE designed this unit to simplify installation while ensuring reliable signal continuity.
You can mount IC694TBB032 directly onto compatible I/O carriers without additional adapters.
This configuration reduces wiring complexity and improves long-term maintenance efficiency.
Specification
| Parameter | Detailed Specification |
|---|---|
| Manufacturer | GE Fanuc (General Electric) |
| Model Number | IC694TBB032 |
| Product Category | Terminal Block |
| Series Compatibility | GE Series 90-30 PLC platform |
| Terminal Positions | 32 individual screw-clamp terminals |
| Terminal Type | Compression screw terminals |
| Supported I/O Type | Discrete input and output modules |
| Mounting Method | Direct attachment to Series 90-30 I/O carrier |
| Field Wiring Connection | Front-access screw termination |
| Wire Gauge Range | 14–22 AWG solid or stranded copper conductors |
| Maximum Wire Insulation Diameter | Approximately 3.0 mm |
| Tightening Torque | 0.5–0.6 N·m recommended |
| Contact Material | Tin-plated copper alloy |
| Insulation Material | Flame-retardant thermoplastic housing |
| Color | Industrial black housing with white numbering |
| Numbering Identification | Clearly printed terminal numbering 1–32 |
| Rated Voltage | 150 VDC / 120 VAC (typical discrete applications) |
| Rated Current per Point | Up to 2 A per terminal (depending on module rating) |
| Insulation Resistance | ≥100 MΩ at 500 VDC |
| Dielectric Withstand Voltage | 1500 VAC for 1 minute |
| Operating Temperature Range | 0°C to 60°C |
| Storage Temperature Range | -40°C to 85°C |
| Relative Humidity | 5%–95% non-condensing |
| Vibration Resistance | Designed for industrial control cabinet environments |
| Shock Resistance | Complies with PLC system mechanical standards |
| Dimensions (H × W × D) | Approx. 130 × 36 × 100 mm (5.1 × 1.4 × 3.9 in) |
| Net Weight | Approx. 0.3 kg |
| Application | Field signal termination for Series 90-30 PLC I/O systems |
| Compliance | Designed to meet industrial control safety standards |
FAQ
Q1: Is the IC694TBB032 new and original?
Yes, we supply brand-new original factory units with guaranteed authenticity.
Q2: Do you keep IC694TBB032 in stock?
We maintain available inventory for most orders in our warehouse.
Q3: How quickly can you ship the product?
We ship within 3 days to 2 weeks depending on order size.
Q4: Which logistics carriers do you use?
We commonly use DHL and other major international courier services.
Q5: What wire size does IC694TBB032 support?
The terminal block supports 14–22 AWG copper conductors securely.
Q6: What if the product has a quality issue?
We support returns within 30 days if any quality problem occurs.
