Overview
It provides a robust, organized framework to securely house multiple I/O and controller modules.
Moreover, its rear-mount design optimizes wiring management and reduces maintenance complexity.
Engineers rely on this rack to build scalable and high-performance industrial automation systems.
In addition, the rack ensures stable mechanical support for modules, preventing connection faults.
Therefore, it is ideal for demanding factory automation, process control, and high-density I/O environments.
Its modular construction allows future system expansion without significant downtime or reconfiguration.
Specification
| Parameter | Specification |
|---|---|
| Brand | GE |
| Model | IC698CHS009 |
| Module Type | Rx7i PacSystem 9-Slot Rear Mount Rack |
| Number of Slots | 9 standard module slots |
| Mounting Type | Rear-mount for control panels and enclosures |
| Supported Modules | Rx7i controllers, I/O modules, communication modules |
| Material | High-strength steel with anti-corrosion coating |
| Dimensions | 76 mm W × 324 mm H × 254 mm D |
| Weight | 3.2 kg (empty) |
| Slot Pitch | Standard Rx7i spacing |
| Wiring Access | Rear-mounted for optimized cable routing |
| Cooling | Natural convection; compatible with forced air systems |
| Certifications | CE, UL, RoHS compliant |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 70°C |
| Relative Humidity | 5–95%, non-condensing |
| Application Scope | Industrial automation, factory control, process control systems |
FAQ
Q1: How many modules can the IC698CHS009 rack hold?
It supports up to 9 Rx7i PacSystem modules simultaneously.
Q2: Can it be installed in existing control panels?
Yes, its rear-mount design is compatible with standard control panels and enclosures.
Q3: What type of modules are compatible with this rack?
It supports Rx7i controllers, I/O modules, and communication modules.
Q4: What are the operating temperature specifications?
The rack operates safely between 0°C and 55°C.
Q5: Does the rack allow for easy maintenance and expansion?
Yes, rear mounting and organized slot design enable simple maintenance and future expansion.
