Overview
Specification
| Parameter | Specification |
|---|---|
| Brand | GE |
| Model | IC697CHS750 |
| Series | Series 90-70 |
| Module Type | 5-Slot Rear-Mount Rack / Chassis |
| Number of Slots | 5 |
| Mounting Style | Rear-mount, panel-mountable |
| Compatible Modules | CPUs, Digital/Analog I/O, Communication modules of Series 90-70 |
| Construction Material | High-strength, corrosion-resistant steel |
| Slot Pitch | Standard 1.25 in per module |
| Backplane Connector Type | Standard Series 90-70 connector for each slot |
| Dimensions (H × W × D) | 2.5 × 12 × 12 in (63.5 × 305 × 305 mm) |
| Weight | 2.8 kg (approx.) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5–95%, non-condensing |
| Altitude | Up to 2,000 m (6,562 ft) |
| Cooling Method | Passive convection airflow |
| Vibration Tolerance | Meets industrial IEC vibration standards |
| Shock Resistance | Complies with IEC industrial shock ratings |
| EMI/RFI Immunity | Designed for industrial electromagnetic environments |
| Certifications | UL, CSA, CE |
| Indicators | None (rack only, passive) |
| Mounting Hardware | Included for standard panel installation |
| Maintenance Features | Clear slot labeling, easy module access for replacement |
| Expansion Capability | Supports seamless integration of additional Series 90-70 modules |
FAQ
A1: It supports all GE Series 90-70 CPUs, I/O, and communication modules.
Q2: Can the rack be mounted in standard industrial control panels?
A2: Yes, it is designed for rear-mount installation with included mounting hardware.
Q3: What is the operating temperature range for this rack?
A3: The rack operates reliably from 0°C to 60°C.
Q4: How does the IC697CHS750 handle system expansion?
A4: It allows seamless integration of additional Series 90-70 modules while maintaining backplane stability.
Q5: Is the rack durable in harsh industrial environments?
A5: Yes, its high-strength steel construction ensures long-term durability and resistance to vibration.
