Overview
Engineers rely on this module to maintain system uptime across complex process and discrete applications. Therefore, it plays a critical role in ensuring deterministic control performance within mission-critical installations. Its compact design allows seamless integration into standard Rx3i baseplates without additional mechanical modification.
Built for industrial reliability, the IC695PD040 withstands electrical noise, temperature variation, and continuous duty operation. In addition, its efficient internal regulation reduces heat generation and enhances long-term component durability.
Specification
| Parameter | Specification |
|---|---|
| Model Number | IC695PD040 |
| Manufacturer | GE |
| Product Type | Universal Base Power Supply |
| Series Compatibility | PACSystems RX3i |
| Primary Function | Provides regulated backplane power for RX3i universal base |
| Nominal Input Voltage | 24 VDC |
| Input Voltage Range | 18–30 VDC |
| Maximum Input Current | Approx. 4 A (depending on load configuration) |
| Inrush Current | Limited by internal circuitry |
| Backplane Output Voltage | Regulated internal system voltages for RX3i modules |
| Output Power Capacity | Supports CPU and multiple I/O modules per base |
| Efficiency | High-efficiency switching power conversion design |
| Isolation | Input-to-backplane electrical isolation |
| Protection – Overcurrent | Electronic current limiting with automatic recovery |
| Protection – Short Circuit | Integrated short-circuit protection |
| Protection – Thermal | Internal temperature monitoring with shutdown protection |
| Status Indicators | Front-panel LED for power and fault status |
| Mounting Method | Direct insertion into RX3i universal base slot |
| Cooling Method | Natural convection, no external fan required |
| Operating Temperature Range | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature Range | –40°C to +85°C (–40°F to 185°F) |
| Relative Humidity | 5% to 95%, non-condensing |
| Vibration Resistance | Designed for industrial control cabinet environments |
| EMC Compliance | Meets industrial EMC standards for automation systems |
| Certifications | UL listed, CE compliant |
| Typical Applications | Process control, manufacturing automation, distributed I/O systems |
FAQ
A1: The module is designed specifically for GE PACSystems RX3i universal base installations.
Q2: What input voltage does this power supply require?
A2: It operates on a nominal 24 VDC input within an 18–30 VDC range.
Q3: Does the IC695PD040 provide protection against overload conditions?
A3: Yes, it includes built-in overcurrent and thermal protection mechanisms.
Q4: Can this module support high-density I/O configurations?
A4: Yes, it provides sufficient regulated power for typical CPU and multi-module rack setups.
Q5: Is it suitable for continuous industrial operation?
A5: Yes, the design supports continuous duty cycles in industrial control environments.
