Overview
Specification
| Parameter | Specification |
|---|---|
| CPU Type | Redundancy CPU, Max-ON Hot-Standby |
| Processor Type | 32-bit microprocessor |
| Memory | 2 MB user memory, 1 MB system memory |
| Scan Time | 1 ms per 1,000 Boolean instructions |
| Program Capacity | Up to 2 MB user program |
| Redundancy Mode | Max-ON Hot-Standby |
| I/O Bus Support | Standard Rx3i backplane |
| Input Voltage | 5 VDC from backplane |
| Output Voltage | 5 VDC for internal logic |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions (HxWxD) | 175 mm x 100 mm x 115 mm |
| Weight | ~1.0 kg |
| LED Indicators | RUN, FAULT, REDUNDANCY, COMM status |
| Communications | Supports serial, Ethernet, and Rx3i I/O modules |
| Certifications | UL, CE, CSA |
| Recommended Maintenance | Verify backplane connections and system diagnostics periodically |
FAQ
A1: It allows the backup CPU to take over immediately if the primary CPU fails, ensuring continuous operation.
Q2: What is the CPU memory capacity?
A2: The module provides 2 MB user memory and 1 MB system memory for programs and data.
Q3: Can it integrate with Rx3i I/O modules?
A3: Yes, it is fully compatible with all standard Rx3i backplanes and I/O modules.
Q4: What operating temperature range does the IC695CMU310 support?
A4: It operates reliably from 0°C to 60°C, with storage up to 85°C.
Q5: How can I monitor system status?
A5: LED indicators show RUN, FAULT, REDUNDANCY, and communication status for quick diagnostics.
