Overview
It enables robust and reliable serial communication between PLC controllers, remote I/O, and peripheral devices.
Engineers use this module to integrate legacy serial devices into modern industrial automation networks.
Moreover, it supports high-speed data transfer while maintaining system integrity across complex automation architectures.
This module simplifies network configuration and reduces wiring complexity, allowing faster deployment and reduced commissioning time.
Therefore, it is ideal for process control, manufacturing automation, and distributed control applications requiring serial connectivity.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | GE Fanuc Automation |
| Product Series | Rx3i PacSystem |
| Model Number | IC695CMM004 |
| Module Type | Serial Communications Module |
| Supported Protocols | Modbus RTU, DF1, ASCII, Custom Serial Protocols |
| Serial Ports | One RS-232 / RS-485 port |
| Maximum Baud Rate | 115.2 kbps |
| Addressing | Supports multiple node addressing schemes |
| Communication Distance | Up to 1200 meters (RS-485) |
| Diagnostic Features | LED status indicators for Power, Run, Fault, and Serial Activity |
| Memory Requirements | Uses local module memory for buffering and error handling |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -25°C to 85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Power Supply | Powered via backplane from Rx3i rack |
| Mounting | Single-slot module in standard Rx3i rack |
| Compliance | CE, UL recognized, industrial automation standards |
| Typical Applications | Process control networks, distributed automation, serial device integration |
FAQ
Q1: Which PLC platform is IC695CMM004 compatible with?
A1: It is designed for the GE Rx3i PacSystem platform and integrates with compatible backplane modules.
Q2: What serial protocols does this module support?
A2: It supports Modbus RTU, DF1, ASCII, and other custom serial protocols.
Q3: How many serial ports does the module provide?
A3: It has one RS-232 / RS-485 serial port.
Q4: Can the module communicate with multiple devices simultaneously?
A4: Yes, it manages multiple nodes and supports high-speed data transfer without overloading the CPU.
Q5: Is the module suitable for long-distance serial communication?
A5: Yes, RS-485 communication supports distances up to 1200 meters.
Q6: Does the module include diagnostic features?
A6: Yes, it has LED indicators for power, run, fault, and serial activity to simplify troubleshooting.
