Overview
Specification
| Parameter | Specification / Details |
|---|---|
| Module Type | Digital Output Module |
| Series / Platform | GE Rx3i PACSystems |
| Number of Channels | 16 discrete digital output channels |
| Output Type | Sourcing or sinking DC |
| Output Voltage | 5–60 VDC |
| Output Current | 0.5 A per channel (maximum) |
| Output Configuration | Individually configurable per channel |
| Switching Speed | 1 ms typical |
| Output Isolation | Channel-to-channel and channel-to-backplane |
| Short Circuit Protection | Built-in protection per channel |
| Status Indicators | LED indicators for each channel |
| Diagnostic Features | Channel failure detection, output range error, backplane communication monitoring |
| Operating Temperature | 0–60°C (32–140°F) |
| Storage Temperature | -40–85°C (-40–185°F) |
| Relative Humidity | 5–95% non-condensing |
| Vibration / Shock Resistance | IEC 60068-2-6, IEC 60068-2-27 compliant |
| Mounting | Rx3i I/O rack, hot-swappable |
| Power Requirements | Supplied by backplane: 5 VDC, typical current 200 mA |
| Module Dimensions | 12.7 mm (W) x 100 mm (H) x 130 mm (D) |
| Weight | Approx. 200 g |
| Certifications | CE, UL, CSA |
| Typical Applications | Motor control, solenoid switching, relay operation, industrial process automation |
| Safety Standards | Meets industrial safety standards for discrete output modules |
| Recommended Maintenance | Periodic inspection and testing of channels for optimal reliability |
FAQ
Q1: How many digital output channels does the IC694MDL741 support?
A1: The module provides 16 discrete digital output channels, which allows precise control of DC loads in various industrial applications.
Q2: What output voltage and current ranges are supported?
A2: It supports 5–60 VDC and delivers up to 0.5 A per channel, ensuring flexible operation for different devices.
Q3: Can the module be replaced while the system is running?
A3: Yes, the IC694MDL741 supports hot-swappable replacement, so you can maintain system uptime without interruption.
Q4: What diagnostic features are included?
A4: In addition, the module provides LED indicators for each channel, channel failure detection, and backplane communication monitoring.
Q5: What environmental conditions can the module operate under?
A5: It operates reliably from 0–60°C with 5–95% non-condensing humidity, and it withstands industrial shock and vibration.
Q6: Is this module compatible with other PACSystems devices?
A6: Yes, it integrates seamlessly with Rx3i I/O racks and PACSystems controllers, enabling scalable and flexible automation solutions.
