Overview
It delivers precise analog output control for industrial processes requiring stable and repeatable signal generation.
Moreover, the module supports multiple output ranges, allowing engineers to drive various field devices reliably.
Therefore, it plays a critical role in systems where output accuracy directly influences process quality.
Specification
| Parameter Category | Specification Details |
|---|---|
| Manufacturer | GE Automation / GE Fanuc |
| Product Family | PACSystems Rx3i |
| Model Number | IC695ALG808 |
| Module Type | Isolated Analog Output Module |
| Output Channels | 8 independent isolated analog output channels |
| Output Signal Types | Analog Voltage and Analog Current |
| Supported Voltage Ranges | 0 to 10 VDC; −10 to +10 VDC |
| Supported Current Ranges | 0 to 20 mA; 4 to 20 mA |
| Output Resolution | 16-bit |
| D/A Conversion Type | High-resolution digital-to-analog conversion |
| Output Accuracy | ±0.1% of full scale typical |
| Output Linearity | ±1 LSB typical |
| Output Update Time | Less than 10 ms per channel typical |
| Channel-to-Channel Isolation | Yes |
| Field-to-Backplane Isolation | Yes |
| Load Resistance (Voltage) | ≥2 kΩ |
| Load Resistance (Current) | Up to 600 Ω |
| Short-Circuit Protection | Electronic current limiting |
| Data Format | Signed integer |
| PLC Compatibility | GE PACSystems Rx3i CPUs |
| Slot Requirement | One standard Rx3i backplane slot |
| Configuration Software | GE Proficy Machine Edition |
| Backplane Power Consumption | Supplied by Rx3i power system |
| Operating Temperature | 0 °C to 60 °C (32 °F to 140 °F) |
| Storage Temperature | −40 °C to 85 °C |
| Relative Humidity | 5% to 95%, non-condensing |
| Vibration Resistance | Meets GE industrial specifications |
| Terminal Type | Removable industrial terminal block |
| Recommended Wiring | Shielded twisted-pair cabling |
| Status Indicators | Module status LED and individual channel LEDs |
| Diagnostics | Output fault detection and module self-diagnostics |
| Typical Applications | Process control, actuator driving, motion and regulation systems |
FAQ
Q1: What output signals does the IC695ALG808 support?
A1: The module supports standard voltage and current outputs, including 0–10 VDC and 4–20 mA.
Q2: How many output channels are available on this module?
A2: IC695ALG808 provides eight fully isolated analog output channels.
Q3: Is this module compatible with all Rx3i controllers?
A3: Yes, it is designed for full compatibility with GE PACSystems Rx3i CPUs.
Q4: Does the module support electrical isolation?
A4: Moreover, each channel includes isolation to improve signal stability and system protection.
Q5: Can this module be used in retrofit projects?
A5: Therefore, it is frequently selected for upgrades due to its standard form factor and flexibility.
