Specification
| Parameter | Specification |
|---|---|
| Module Type | Power Supply Module |
| Input Voltage | 120/240 VAC ±10%, 50/60 Hz |
| Output Voltage | 5 VDC / 24 VDC |
| Output Current | 5 VDC: 7 A, 24 VDC: 4 A |
| Output Ripple & Noise | <50 mV peak-to-peak |
| Efficiency | >85% |
| Power Dissipation | 15 W typical |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions (HxWxD) | 190 mm x 120 mm x 115 mm |
| Weight | ~1.2 kg |
| Mounting | Standard Rx3i rack backplane |
| Protection Features | Overvoltage, overcurrent, short-circuit |
| LED Indicators | Power ON, Status, Fault |
| Certifications | UL, CE, CSA |
| Recommended Maintenance | Periodic inspection; verify ventilation; check connections |
FAQ
A1: It provides 5 VDC at 7 A and 24 VDC at 4 A outputs for Rx3i PLC modules.
Q2: What protections are included in this power supply?
A2: The module includes overvoltage, overcurrent, and short-circuit protection.
Q3: Can this module operate in high-temperature environments?
A3: Yes, it operates reliably between 0°C and 60°C with storage up to 85°C.
Q4: How can I monitor its status?
A4: LED indicators show power, operational status, and fault conditions.
Q5: Is it compatible with all Rx3i backplanes?
A5: Yes, it integrates seamlessly with standard Rx3i racks for scalable system expansion.
