Overview
Specification
| Parameter | Specification |
|---|---|
| Input Voltage Range | 120–240 VAC, single-phase, 50/60 Hz |
| Input Current | 3.5 A at 120 VAC; 1.8 A at 240 VAC |
| Input Power | 420 W maximum |
| Output Voltage (DC) | 5 VDC ±2%; 24 VDC ±2% |
| Output Current | 5 VDC: 10 A; 24 VDC: 15 A |
| Total Output Power | 375 W |
| Efficiency | ≥85% typical at full load |
| Hold-up Time | ≥10 ms at full load |
| Power Factor | ≥0.95 |
| Regulation | Line: ±1%; Load: ±2% |
| Ripple & Noise | 50 mV peak-to-peak max |
| Isolation Voltage | Input to output: 1500 VAC; Input to ground: 1500 VAC |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5–95% RH, non-condensing |
| Vibration | 5–9 Hz: 3.5 mm double amplitude; 9–150 Hz: 10 m/s² |
| Shock | 15 g, 11 ms half-sine |
| Mounting Options | DIN-rail or panel mount |
| Dimensions | 3.0 in W × 4.5 in H × 6.0 in D (76 × 114 × 152 mm) |
| Weight | 1.5 kg (3.3 lbs) |
| Protection Features | Overcurrent, short-circuit, thermal shutdown, overvoltage |
| Certifications | UL Listed, CSA Certified, CE Compliant |
| Redundancy Capability | Supports dual/redundant configurations for critical systems |
| Indicators | LED status for power OK and fault conditions |
| Connection Type | Screw terminal block for DC output; standard IEC input connector |
| Compatibility | Fully compatible with GE Series 90-30 PLC CPUs and I/O modules |
FAQ
A1: Yes, it fully supports all standard and expansion modules in the Series 90-30 PLC system.
Q2: What protection features does this power supply include?
A2: It includes over-voltage, over-current, and short-circuit protection to ensure system safety.
Q3: Can it operate in high-temperature environments?
A3: The module supports operating temperatures up to 60°C and storage temperatures up to 85°C.
Q4: How can I monitor its operational status?
A4: Built-in LEDs indicate power, status, and fault conditions for easy diagnostics.
Q5: What maintenance is recommended for long-term reliability?
A5: Periodic inspection, proper ventilation, and consulting GE support for firmware or system updates are recommended.
