Overview
Engineers actively deploy this unit to supervise energy usage, maintain load balance, and improve electrical efficiency in demanding environments. Furthermore, the module supports proactive energy management strategies by providing consistent, traceable data.
Designed specifically for industrial conditions, the IC693PTM101 combines measurement accuracy with seamless PLC integration. Therefore, it reduces panel complexity while maintaining dependable long-term operation. In addition, the module communicates directly through the backplane, which simplifies configuration and accelerates diagnostics within the PLC program. Consequently, maintenance teams resolve power-related issues faster and minimize unexpected downtime.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | GE Intelligent Platforms |
| Product Series | Series 90-30 |
| Model Number | IC693PTM101 |
| Module Type | Power Transducer Module |
| Mounting Method | Rack-mounted, Series 90-30 baseplate slot |
| Backplane Interface | 90-30 PLC backplane bus |
| Measured Electrical Quantity | Real Power (kW) |
| Input Voltage Type | Via external Potential Transformer (PT) |
| Input Current Type | Via external Current Transformer (CT) |
| Nominal Voltage Input Range | Determined by external PT ratio |
| Nominal Current Input Range | Determined by external CT ratio |
| Input Signal Isolation | Galvanic isolation between field inputs and PLC backplane |
| Signal Conversion | Internal analog-to-digital processing for PLC data registers |
| Data Resolution | PLC word-based digital representation |
| Accuracy | Dependent on CT/PT accuracy and system calibration |
| Response Time | Suitable for real-time PLC scan cycles |
| Power Consumption | Supplied through PLC backplane |
| Heat Dissipation | Designed for standard 90-30 cabinet ventilation |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Vibration Resistance | Meets industrial PLC mounting standards |
| Dimensions | Standard Series 90-30 single-slot module form factor |
| Installation Location | Local or expansion baseplate within 90-30 system |
| System Compatibility | Compatible with GE Series 90-30 CPUs |
| Programming Support | Configured through Proficy Machine Edition |
| Typical Application Voltage Systems | Single-phase or three-phase systems using external transformers |
| Typical Use Case | Industrial power monitoring and load analysis within PLC control systems |
FAQ
A1: The module measures real power using voltage and current transformer inputs.
Q2: Can this module operate without external transformers?
A2: No, appropriate voltage and current transformers are required for accurate measurement.
Q3: Is the IC693PTM101 compatible with all Series 90-30 CPUs?
A3: Yes, it is designed for integration with standard GE Series 90-30 PLC systems.
Q4: Does the module support energy management applications?
A4: Yes, it provides real-time power data suitable for monitoring and optimization programs.
Q5: Can the module be used in noisy industrial environments?
A5: Yes, it is engineered for reliable performance under typical industrial electrical conditions.
