Overview
It allows engineers to drive solenoids, relays, and other discrete devices with precision and stability.
Moreover, the module supports high-speed switching and robust isolation for critical industrial applications.
Engineers benefit from simplified wiring, built-in diagnostics, and compatibility with a wide range of automation devices.
Therefore, plants can achieve reliable output control while minimizing downtime and maintenance complexity.
The IC693MDL732 integrates seamlessly into Series 90-30 PLC racks for easy system expansion.
In addition, it ensures accurate signal delivery to connected devices under demanding industrial conditions.
Specification
| Parameter | Specification |
|---|---|
| Model Number | IC693MDL732 |
| Manufacturer | GE |
| Device Type | Digital Output Module for PLC |
| Compatible Series | Series 90-30 |
| Number of Output Channels | 16 discrete outputs |
| Output Type | Sourcing or sinking configurable |
| Output Voltage | 5–60 VDC |
| Output Current | 0.5 A per channel maximum |
| Isolation | Optical isolation from backplane and channel-to-channel |
| Switching Speed | 1 ms typical per channel |
| Status Indicators | Individual LEDs for each output channel |
| Power Supply | 5 V DC from backplane |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | –20°C to +85°C (–4°F to 185°F) |
| Mounting | Series 90-30 backplane rack |
| Protection | Overcurrent and short-circuit protection per channel |
| Certifications | UL, CE, IEC 61131-3 compliant |
| Applications | Motor control, solenoid actuation, indicator control, automated machinery |
FAQ
A1: The module provides 16 discrete digital output channels.
Q2: What is the maximum output current per channel?
A2: Each channel supports up to 0.5 A.
Q3: Does the module offer diagnostic indicators?
A3: Yes, each channel has a status LED for troubleshooting and monitoring.
Q4: What types of devices can it control?
A4: It can control relays, solenoids, motors, and indicator lights.
Q5: Is it compatible with Series 90-30 PLCs?
A5: Yes, it integrates fully with Series 90-30 backplane racks.
