Overview
It enables direct control and monitoring of DeviceNet field devices from the PLC processor.
Moreover, the module acts as a master scanner, coordinating data exchange across the entire DeviceNet network.
Engineers select this module when they require deterministic device-level communication in distributed automation systems.
Therefore, it reduces hardwired I/O while improving system flexibility and scalability.
In addition, seamless integration with the Series 90-30 backplane simplifies configuration and diagnostics.
The IC693DNM200 supports efficient data mapping between DeviceNet nodes and PLC memory registers.
As a result, operators gain real-time access to remote sensors, drives, and actuators.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | GE Intelligent Platforms |
| Product Series | Series 90-30 |
| Model Number | IC693DNM200 |
| Module Type | DeviceNet Master / Scanner Module |
| Mounting Method | Rack-mounted, single-slot module |
| Backplane Interface | Series 90-30 PLC backplane bus |
| Primary Function | DeviceNet network master and I/O scanner |
| Network Protocol | ODVA DeviceNet (based on CAN technology) |
| Supported Baud Rates | 125 kbps, 250 kbps, 500 kbps (selectable) |
| Maximum Number of Slave Devices | Up to 63 DeviceNet nodes |
| Node Addressing | Configurable via software or network settings |
| Messaging Types Supported | Cyclic I/O messaging and explicit messaging |
| I/O Data Handling | Automatic data exchange between network nodes and PLC memory |
| Data Mapping | Configurable mapping to PLC registers |
| Network Topology | Trunk-line/drop-line DeviceNet architecture |
| Physical Layer | CAN-based differential signaling |
| Network Connector | Standard 5-pin DeviceNet interface |
| Network Power | Supplied externally per DeviceNet specifications |
| Module Power Supply | Powered directly from PLC backplane |
| Electrical Isolation | Isolation between DeviceNet network and PLC backplane |
| LED Indicators | Module status, network status, and communication activity |
| Configuration Tool | Proficy Machine Edition |
| Compatible CPUs | GE Series 90-30 PLC processors |
| Installation Location | Local baseplate or expansion baseplate slot |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Vibration Resistance | Designed for industrial control cabinet environments |
| Typical Applications | Distributed I/O systems, drives, intelligent motor control, remote sensors |
| Compliance | Designed in accordance with industrial DeviceNet standards |
FAQ
A1: It serves as a DeviceNet master scanner within the Series 90-30 PLC system.
Q2: How many DeviceNet devices can the module support?
A2: It can manage communication with up to 63 DeviceNet slave devices.
Q3: Which baud rates does the IC693DNM200 support?
A3: The module supports 125 kbps, 250 kbps, and 500 kbps network speeds.
Q4: Can engineers configure the module through standard PLC software?
A4: Yes, configuration is completed using Proficy Machine Edition tools.
Q5: Is the module suitable for distributed automation systems?
A5: Yes, it is specifically designed for distributed DeviceNet-based architectures.
