Overview
It provides a compact mounting platform for distributed modules in remote control cabinets.
Moreover, the baseplate enables efficient signal routing between field devices and the central processor.
Engineers install this unit when machine layouts require decentralized I/O placement.
Therefore, it reduces long cable runs and simplifies overall panel wiring.
In addition, the rugged chassis design ensures mechanical stability under industrial operating conditions.
The IC693CHS399 integrates seamlessly with compatible remote interface modules and power supplies.
As a result, system architects achieve flexible expansion without modifying existing PLC logic.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | GE Intelligent Platforms |
| Product Series | Series 90-30 PLC |
| Model Number | IC693CHS399 |
| Module Type | Remote Baseplate for I/O and Communication Modules |
| Application | Distributed I/O expansion in industrial automation |
| Number of Slots | 5 standard Series 90-30 module slots |
| Backplane Interface | Series 90-30 internal bus architecture |
| Compatible Modules | Series 90-30 digital, analog, and interface modules |
| Remote Operation Support | Yes, via compatible remote interface modules |
| Power Distribution | Power supply requires compatible Series 90-30 PSU module |
| Slot Orientation | Standard horizontal alignment, keyed for correct insertion |
| Mechanical Construction | Industrial-grade metal chassis with precision machined guides |
| Mounting Method | Panel or cabinet rail mounting within control enclosure |
| Mounting Dimensions | Standard Series 90-30 form factor spacing |
| Connector Type | 90-30 backplane edge connectors for each slot |
| Signal Integrity Features | Backplane bus contact retention and EMI suppression design |
| Electrical Isolation | Required per installed I/O module specifications |
| Operating Temperature Range | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature Range | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Shock & Vibration | Designed to meet industrial control cabinet standards |
| Environmental Suitability | Indoor industrial spaces, panel-mounted configurations |
| Safety & Compliance | Built to match Series 90-30 industrial safety and operational standards |
| Serviceability | Easy slot access for field replacement or upgrades |
| Documentation Support | Proficy Machine Edition and Series 90-30 manuals |
FAQ
Q1: How many modules can the IC693CHS399 support?
A1: It supports up to five Series 90-30 I/O or communication modules.
Q2: Is this baseplate suitable for remote installations?
A2: Yes, it is designed specifically for remote I/O expansion applications.
Q3: Does the baseplate include a power supply?
A3: No, it requires a compatible Series 90-30 power supply module.
Q4: Can it operate in industrial environments?
A4: Yes, it supports standard industrial temperature and humidity ranges.
Q5: Is it compatible with all 90-30 I/O modules?
A5: Yes, it supports standard Series 90-30 I/O and communication modules.
