Overview
It enables seamless communication for downloading, uploading, and debugging PLC programs efficiently.
Moreover, its rugged design ensures consistent performance in industrial environments.
Engineers can rely on this cable for accurate and stable data transfer between controllers and PCs.
Therefore, commissioning and maintenance tasks become faster and more predictable.
Its plug-and-play compatibility minimizes configuration effort and system integration time.
Specification
| Category | Parameter | Specification |
|---|---|---|
| General Information | Model Number | IC690ACC901 |
| Product Type | Programming Cable | |
| Compatible Systems | GE Series 90-30 PLCs | |
| Function | PLC programming, diagnostics, and firmware updates | |
| Electrical Characteristics | Signal Type | Serial RS-232 / System-specific protocol |
| Connector Type | DB9 male/female (PC to PLC) | |
| Cable Shielding | Foil and braid for EMI protection | |
| Cable Length | Standard 1.8 meters (6 feet) | |
| Mechanical Characteristics | Jacket Material | Flexible PVC for industrial durability |
| Connector Plating | Gold-plated contacts for reliable signal | |
| Flexibility | Suitable for cabinet routing and frequent handling | |
| Environmental Specifications | Operating Temperature | 0°C to 60°C |
| Storage Temperature | –40°C to 85°C | |
| Humidity | 5–95% non-condensing | |
| Vibration & Shock | Designed for control panel and industrial use | |
| Compliance & Standards | Certifications | CE and UL system-compliant design |
| Application Environment | Industrial automation, PLC programming |
FAQ
A1: It connects GE Series 90-30 PLCs to programming devices for program download and diagnostics.
Q2: Which systems are compatible with this programming cable?
A2: It is compatible with all GE Series 90-30 PLC controllers.
Q3: How long is the standard cable length?
A3: The standard cable length is 1.8 meters (6 feet).
Q4: Does the cable include shielding against interference?
A4: Yes, it has foil and braid shielding to reduce EMI in industrial panels.
Q5: Are the connectors durable for repeated use?
A5: Yes, gold-plated contacts ensure long-term reliability and signal integrity.
