Overview
It delivers stable and regulated power to CPUs, I/O modules, and communication interfaces.
As a result, engineers achieve consistent system startup and dependable long-term operation.
Moreover, its compact footprint supports high-density control panels and distributed automation architectures.
In addition, the module connects directly to the VersaMax backplane without complex auxiliary wiring.
Therefore, technicians complete installation quickly in both new projects and retrofit applications.
Consequently, integrators reduce commissioning time while maintaining reliable power distribution.
Specification
| Parameter | Specification |
|---|---|
| Model Number | IC200PWR101 |
| Series | VersaMax |
| Manufacturer | GE Intelligent Platforms |
| Module Type | AC Power Supply Module |
| Primary Function | Provides regulated logic power to VersaMax backplane |
| Input Voltage Range | 120/240 VAC, auto-ranging |
| Input Voltage Tolerance | Typical industrial tolerance ±10% |
| Input Frequency | 47–63 Hz |
| Inrush Current | Controlled at startup to protect upstream circuits |
| Input Protection | Internal fuse and surge suppression |
| Output Voltage | 5 VDC (logic power for backplane) |
| Maximum Output Current | Approx. 1.5 A (system dependent) |
| Output Regulation | Maintains stable DC output under rated load |
| Ripple and Noise | Industrial-grade filtered output for PLC stability |
| Isolation | Input-to-backplane isolation provided |
| Efficiency | Designed for high-efficiency operation in compact enclosures |
| Status Indicators | Power OK LED, Fault/Status LED |
| Diagnostics | Visual fault indication for overload or internal fault |
| Mounting Method | Direct installation on VersaMax backplane |
| Wiring Connection | Screw terminal for AC input connection |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5–95% non-condensing |
| Cooling Method | Natural convection, no external fan required |
| Vibration Resistance | Suitable for standard industrial environments |
| EMC Compliance | Designed to meet industrial EMC standards |
| Safety Compliance | Meets relevant industrial safety certifications |
| Dimensions | Compact modular format for panel integration |
| Weight | Lightweight module for modular rack systems |
FAQ
Q1: What PLC platform is the IC200PWR101 designed for?
A: The IC200PWR101 is specifically designed for the GE VersaMax modular PLC system.
Q2: What input voltage does this power supply accept?
A: It supports 120/240 VAC input with automatic voltage range selection.
Q3: What output does the module provide to the system?
A: It delivers regulated 5 VDC logic power to the VersaMax backplane.
Q4: How much output current is available?
A: The module provides approximately 1.5 A of backplane current, depending on system load.Q5: Can this module power all installed I/O modules?
A: It can power compatible CPUs and I/O modules within the calculated backplane current limit.
