Overview
Engineers often select this module when industrial processes require accurate measurement from multiple thermocouple sensors across production equipment.
Moreover, the module provides high-resolution signal conversion, which helps maintain stable temperature monitoring in demanding industrial environments.
Its 16-bit analog resolution ensures precise thermal data acquisition, improving control performance in temperature-critical processes.
Therefore, many system integrators deploy the IC200ALG630 module within PLC architectures that demand reliable and scalable temperature monitoring.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric |
| Model Number | IC200ALG630 |
| Product Type | Thermocouple Analog Input Module |
| Series | VersaMax Distributed I/O |
| Input Channels | 8 thermocouple input channels |
| Supported Thermocouple Types | Common industrial types such as J, K, T, E, R, S, and B |
| Measurement Resolution | 16-bit analog-to-digital conversion |
| Measurement Function | Temperature monitoring using thermocouple sensors |
| Cold Junction Compensation | Integrated automatic cold junction compensation |
| Input Configuration | Differential thermocouple measurement |
| Conversion Method | Integrated A/D conversion with digital signal processing |
| Diagnostic Indicators | LED indicators for module power and operational status |
| Backplane Communication | VersaMax I/O backplane interface |
| Configuration | Configured through VersaMax PLC programming software |
| Mounting Method | Installed on VersaMax I/O carrier or baseplate |
| System Compatibility | VersaMax PLC CPUs and distributed I/O networks |
| Power Supply | Powered through the VersaMax backplane |
| Operating Temperature | Designed for industrial control cabinet environments |
| Storage Temperature | Standard industrial storage temperature range |
| Environmental Protection | Designed for factory automation and process environments |
| Typical Applications | Industrial heating systems, furnaces, chemical processing, energy production |
FAQ
Q1: What type of sensors does the IC200ALG630 module support?
The module supports thermocouple temperature sensors including types J, K, T, E, R, S, and B commonly used in industry.
Q2: How many thermocouple channels are available?
The IC200ALG630 module provides eight thermocouple input channels for multi-point temperature monitoring.
Q3: What resolution does the module provide for temperature measurements?
The module uses 16-bit analog-to-digital conversion to deliver high-accuracy thermocouple temperature measurements.
Q4: Which control systems are compatible with this module?
The module integrates with VersaMax PLC platforms developed by General Electric for distributed industrial automation systems.
Q5: Where is the IC200ALG630 module typically used?
Engineers commonly install the module in industrial heating systems, chemical processing plants, and power generation facilities.
