Overview
Engineers often select this module when applications require stable measurement of multiple process transmitters across modern control architectures.
Moreover, the module integrates seamlessly with VersaMax distributed I/O platforms, allowing flexible installation in machine panels or remote cabinets.
Its 15-bit analog resolution enables precise signal conversion, which supports reliable monitoring of industrial sensors and process instrumentation.
Therefore, system integrators commonly deploy this module when building scalable PLC-based control solutions across manufacturing facilities.The IC200ALG265 module processes standard industrial current signals while maintaining excellent noise immunity in electrically demanding environments.
In addition, robust module electronics ensure consistent signal stability even when long cable runs connect field transmitters to control cabinets.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric |
| Model Number | IC200ALG265 |
| Product Type | Analog Input Module |
| Series | VersaMax Distributed I/O |
| Input Channel Count | 8 analog input channels |
| Input Signal Type | Industrial current input |
| Typical Input Range | 4–20 mA |
| Resolution | 15-bit analog-to-digital conversion |
| Input Configuration | Single-ended current input |
| Signal Conversion | High precision A/D conversion with digital processing |
| Accuracy | High-accuracy measurement for industrial process signals |
| Channel Isolation | Designed for industrial electrical safety and signal stability |
| Update Rate | Fast input scanning suitable for real-time process monitoring |
| Diagnostic Indicators | LED status indicators for module health and operation |
| Communication Interface | VersaMax I/O backplane communication |
| Configuration | Configurable through VersaMax PLC programming tools |
| Mounting Method | Installed on VersaMax I/O carrier or baseplate |
| System Compatibility | VersaMax PLC controllers and distributed I/O stations |
| Power Supply | Powered through the VersaMax backplane |
| Environmental Design | Industrial environment rated module |
| Operating Temperature | Suitable for standard industrial cabinet conditions |
| Storage Temperature | Industrial storage temperature range |
| Application Environment | Manufacturing automation, utilities, energy systems, and process control |
FAQ
Q1: What type of signals does the IC200ALG265 module measure?
The module measures industrial current signals, typically 4–20 mA inputs from transmitters and monitoring instruments.
Q2: How many input channels does the module support?
The IC200ALG265 module supports eight independent analog input channels for multi-sensor monitoring applications.
Q3: What resolution does the analog conversion provide?
The module uses 15-bit analog-to-digital conversion, which ensures accurate measurement of industrial process signals.
Q4: Which automation systems support the IC200ALG265 module?
The module integrates with VersaMax PLC platforms developed by General Electric for distributed industrial control systems.
Q5: Where is this module typically used?
Engineers commonly install the module in manufacturing automation systems, energy facilities, and process control environments.
