Overview
The Honeywell 51202329-735, also cataloged as the 51202329-735 Violet Extension Cable, operates as a dedicated hardware component for Series C system cabling and I/O Link 2 communication extensions within Honeywell Experion Control Systems.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 51202329-735 |
| Brand | Honeywell |
| Origin | Global Manufacturing Standards |
| Weight | Approximately 0.3 kg |
| Dimensions | 48 inches (1.2 m) length |
| Operating Temp | 0 deg C to 60 deg C |
| Power Consumption | Passive cabling component (0 W) |
| Product Type | Violet Extension Cable |
| Product Series | Series C |
| Cable System | I/O Link 2 (IOL2) |
| Identification Label | Green (Cable B) |
Process Control System Integration
Configured specifically for DCS instrumentation and control network architectures, the Honeywell 51202329-735 ensures signal integrity across distributed nodes. Although physical cabling primarily handles copper-based interconnects, the associated Series C framework seamlessly supports standard industrial communication parameters, including 4-20 mA HART loop protocols and digital bus networks, by maintaining low insertion loss and robust electromagnetic shielding. Furthermore, channel-to-channel isolation requirements are strictly preserved through proper cable routing and separation within industrial control cabinets.
Frequently Asked Questions
Q: What is the physical distinction between model 51202329-734 and 51202329-735?
A: Both models measure 48 inches in length and feature violet insulation. However, model 51202329-734 is equipped with a yellow label designating Cable A, whereas model 51202329-735 features a green label designating Cable B.
Q: Can this extension cable be utilized independently without its paired cable?
A: No. The extension assembly requires a matched pair comprising Cable A and Cable B to properly establish the dual-path I/O Link 2 connection. The matched pair is ordered under part number 51202329-736.
Field Installation Guidelines
Ensure that the control system power is completely isolated before routing or connecting any I/O Link 2 cables. Carefully route the violet extension cable through dedicated industrial cable trays, maintaining adequate physical separation from high-voltage power lines to prevent signal interference. Secure the connectors firmly to the corresponding Series C interface ports, verifying that the green identification label matches the designated Cable B termination point.
