Overview
Specification
| Parameter / Attribute | Specification / Detail |
|---|---|
| Model Number | DS200SIOBH1ABA |
| Product Type | VME Stand Input/Output Board |
| System Compatibility | GE Mark V Turbine Control System |
| I/O Channels | 16 Digital Inputs, 16 Digital Outputs (configurable), 8 Analog Inputs |
| Input Signal Range | 0–24 V DC for digital, 4–20 mA for analog |
| Output Signal Range | 0–24 V DC digital outputs, 4–20 mA analog outputs |
| Communication Interface | VME backplane (Standard 32-bit) |
| Response Time / Cycle Time | Digital: <1 ms, Analog: 2–5 ms |
| Resolution (Analog Channels) | 12-bit |
| Accuracy (Analog Channels) | ±0.5% |
| Isolation | Galvanic isolation between channels and VME backplane |
| Power Supply | Supplied via Mark V VME chassis |
| Power Consumption | Typical 8 W, Max 12 W |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5–95% non-condensing |
| Vibration Resistance | 5–20 Hz: ±0.5 mm, 20–100 Hz: 2 g |
| Electromagnetic Immunity (EMI/RFI) | IEC61000-4-2 / IEC61000-4-3 compliant |
| Diagnostics / Status Indicators | Onboard LEDs for digital input/output status and system health |
| Dimensions / Form Factor | Standard 6U VME board, 233 mm x 160 mm |
| Weight | Approximately 0.5 kg |
| Compliance | Original GE equipment, industrial-grade certifications |
FAQ
A1: The board supports both digital and analog I/O signals for versatile turbine monitoring.Q2: Is this board compatible with all GE Mark V systems?
A2: Yes, it is designed specifically for GE Mark V turbine control VME chassis integration.
Q3: What environmental conditions can this board operate under?
A3: It operates in 0 °C to 60 °C temperatures and tolerates 5–95% non-condensing humidity.
Q4: Does it provide diagnostic features?
A4: Yes, it includes onboard diagnostic LEDs for status monitoring and troubleshooting.
Q5: Can it withstand industrial vibrations?
A5: Yes, the board is engineered for industrial vibration and EMI resistance.
