Overview
Configured for module termination and physical signal routing in ABB Ethernet FCI and S800 I/O systems, the ABB TUS810 3BSE078716R1 (TUS810 Module Termination Unit) provides direct mechanical mounting and electrical interface support for associated automation hardware.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | TUS810 3BSE078716R1 |
| Base Model | TUS810 |
| Brand | ABB |
| Product Type | Module Termination Unit |
| Application | Ethernet FCI and S800 I/O systems |
| Function | Module mounting, power distribution, and signal routing |
| Width | 135 mm |
| Height | 210 mm |
| Depth | 95.5 mm |
| Dimensions | 135 x 210 x 95.5 mm |
| Weight | 0.5 kg |
ABB Industrial Control Interface Characteristics
The TUS810 3BSE078716R1 supports the physical integration requirements of ABB industrial control architectures. It provides a defined mounting and termination interface for compatible Ethernet FCI and S800 I/O hardware.
Furthermore, the unit supports organized module installation and associated electrical routing within the automation assembly. Correct interface matching depends on the installed ABB communication or I/O module and the applicable system configuration.
The termination unit itself does not define deterministic network performance. Instead, communication behavior depends on the connected Fieldbus Communication Interface, network configuration, firmware compatibility, and system architecture.
Frequently Asked Questions
Q: What is the primary function of the ABB TUS810 3BSE078716R1?
A: The TUS810 functions as a Module Termination Unit for compatible ABB Ethernet FCI and S800 I/O system hardware. It provides physical mounting and associated electrical connection paths.
Q: Does the TUS810 3BSE078716R1 include a communication processor?
A: The provided specifications identify the product as a Module Termination Unit. Communication processing functions depend on the connected ABB interface or communication module.
Q: Is power consumption specified for the TUS810?
A: No specific power consumption value is provided in the available technical data. System power requirements should therefore be evaluated according to the connected module and complete installation configuration.
Field Installation Guidelines
Install the ABB TUS810 3BSE078716R1 only in a compatible enclosure or automation assembly designed for the associated ABB system.
Verify the model number and connected module compatibility before installation. Secure the unit according to the applicable mounting arrangement and avoid mechanical stress on connected wiring.
Route communication and field wiring according to ABB installation practices. In addition, maintain appropriate separation between signal wiring and high-power conductors where required by the system design.
Connect cable shields and protective grounding according to the applicable ABB system documentation. Do not apply power until all module connections and mechanical mounting points have been checked.
