Overview
The ABB 3BSX605032R4, also cataloged as the PU513V2 RTA Board, operates as a dedicated hardware component for real-time adapter communication and data processing within ABB Master Systems and Advant OCS platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 3BSX605032R4 |
| Brand | ABB |
| Origin | Sweden |
| Product Type | RTA Communication Board |
| Board Function | Real-Time Adapter (RTA) communication and control |
| System Compatibility | ABB Master Systems / Advant OCS |
| Communication Interface | Dual-channel MB300 (MasterBus 300) |
| Bus Architecture | ISA / EISA compatible |
| Memory Capacity | 16 MB |
| Installation Platform | AS500 System Units and PC workstations |
Industrial Control Bus Communication Features
The ABB 3BSX605032R4 integrates with ABB industrial control architectures through MB300 communication channels. It supports real-time data exchange between system processors and field-level control resources. The board uses ISA or EISA bus architecture for host system connection and provides 16 MB memory capacity for communication handling and control application execution.
For ABB PLC/DCS platforms, the module supports firmware flash compatibility requirements defined by the host automation environment. The board also maintains backplane bus communication velocity according to the installed Master System hardware configuration, ensuring deterministic data transfer between connected control components.
Frequently Asked Questions
Q: What communication protocol does the ABB 3BSX605032R4 support?
A: The board supports ABB MB300 (MasterBus 300) communication through dual-channel interfaces for Master Systems and Advant OCS architectures.
Q: Can the ABB 3BSX605032R4 be installed in modern Ethernet-based control networks directly?
A: No. The board is designed for ABB legacy control platforms using ISA or EISA bus architectures and MB300 communication interfaces. Additional gateway hardware is required for integration with newer network infrastructures.
Q: Does the ABB 3BSX605032R4 support hot-swap replacement?
A: Hot-swap capability is not specified for this board. Installation and replacement should follow the shutdown and maintenance procedures defined for the applicable ABB AS500 system hardware.
Field Installation Guidelines
- Install the ABB 3BSX605032R4 only in compatible ABB Master System or Advant OCS hardware configurations.
- Verify ISA or EISA bus slot compatibility before mechanical installation.
- Disconnect system power before removing or inserting the communication board.
- Maintain proper grounding between the board chassis, rack assembly, and control cabinet earth point.
- Route communication cables separately from high-voltage power conductors to reduce electromagnetic interference.
- Check MB300 communication cable connections and shielding termination before system startup.
- Confirm firmware compatibility between the RTA board and the installed ABB control system software.
