Overview
The ABB NLWC-03 (3ABD58948233), also cataloged as the NLWC-03 Single Plastic Fibre Optic Cable, operates as a dedicated optical communication component for signal transmission within ABB ACS600 drive platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | NLWC-03 |
| Brand | ABB |
| Product Type | Single Plastic Fibre Optic Cable |
| Product ID | 3ABD58948233 |
| ABB Type Designation | NLWC-03 |
| Catalog Description | NLWC-03, 2x3M single plastic fibre optic cable |
| Cable Length | 2 x 3 m |
| Fibre Type | Plastic fibre optic cable |
| System Compatibility | ABB ACS600 option interface |
| Frame Size | ACS600_option |
| Weight | 0.1 kg |
| Dimensions | 300 cm x 2 cm x 2 cm |
| Power Consumption | Passive component, no external power consumption |
Optical Communication and Drive Interface Characteristics
The ABB NLWC-03 provides optical signal routing between compatible ABB ACS600 option modules and drive system interfaces. The cable uses plastic fibre technology to transmit communication signals without electrical conduction between connected points.
For ACS600 drive configurations, the NLWC-03 supports fibre optic interconnection requirements where electrical isolation, reduced electromagnetic interference exposure, and controlled signal transfer are required. The component contains no active electronics, firmware, or configurable parameters.
The cable installation follows ABB drive system wiring practices. Therefore, technicians should maintain correct fibre routing, avoid excessive bending, and protect the optical ends from contamination during installation.
Frequently Asked Questions
Q: Does the ABB NLWC-03 require an external power supply?
A: No. The NLWC-03 is a passive plastic fibre optic cable and does not consume electrical power.
Q: Can the NLWC-03 be configured through ABB drive firmware?
A: No. The cable contains no firmware or adjustable parameters. Configuration depends on the connected ACS600 hardware and communication modules.
Q: What installation restrictions apply to the NLWC-03?
A: The installer must protect the fibre ends from dust and mechanical damage while maintaining proper cable routing according to ABB installation practices.
Field Installation Guidelines
- Verify that the connected ACS600 option interfaces support the NLWC-03 fibre optic connection before installation.
- Inspect the fibre connectors for contamination or mechanical damage before connection.
- Route the cable separately from high-current power conductors where practical to reduce mechanical and environmental stress.
- Avoid sharp bends, crushing forces, or excessive pulling tension during cable installation.
- Secure the cable to prevent vibration-related movement inside the drive cabinet.
- Keep unused fibre connectors covered with protective caps to prevent optical surface contamination.
.
