Overview
The IS200EDCFG1BAA exciter board manages DC feedback signals within GE EX2100 excitation systems.
GE designed this module to monitor generator field voltage with high precision.
Therefore, power plants rely on this board for stable excitation regulation.
As part of the GE EX2100 platform, IS200EDCFG1BAA processes real-time DC feedback signals.
It converts field voltage inputs into conditioned control signals for system processors.
Moreover, its compact PCB structure ensures reliable integration inside excitation cabinets.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Series | EX2100 Excitation Control System |
| Model | IS200EDCFG1BAA |
| Product Type | Exciter DC Feedback Board |
| Primary Function | Generator field voltage feedback monitoring |
| PCB Construction | Multi-layer industrial-grade epoxy fiberglass board |
| Layer Design | 4–6 layer mixed signal routing structure |
| Approximate Dimensions (H × W × D) | 30.5 cm × 19.0 cm × 2.5 cm |
| Weight | Approximately 0.8 kg |
| Mounting Method | Rack-mounted within EX2100 excitation cabinet |
| Input Signal Type | High-voltage DC field feedback signal |
| Input Voltage Range | Up to 600 VDC (via resistor divider network) |
| Signal Conditioning | Precision resistor divider and amplifier circuitry |
| Power Supply | 5 VDC logic supply from system backplane |
| Power Consumption | Approximately 6–12 W during operation |
| Energy Storage Components | Electrolytic and ceramic capacitors for voltage stabilization |
| Analog Components | Operational amplifiers and signal filtering circuits |
| Connector Type | High-density edge connector for rack interface |
| Isolation Method | Electrical separation between sensing and logic circuits |
| Operating Temperature Range | 0°C to 60°C |
| Storage Temperature Range | –40°C to 85°C |
| Relative Humidity | 5%–95% non-condensing |
| Protective Coating | Conformal coating for industrial protection |
| Application | Gas and steam turbine generator excitation systems |
