Overview
The IS200DSPXH1DBD board delivers high-speed digital signal processing for GE Mark VI systems.
It handles precise control calculations for turbine and generator subsystems.
Consequently, operators maintain optimized performance with minimal signal latency.
Engineers use IS200DSPXH1DBD (also referred to as DSPXH1D) for critical excitation and control functions.
This board integrates with the Mark VI backplane to provide robust real-time communication.
Furthermore, its industrial-grade PCB ensures reliable operation under heavy electrical load.
The IS200DSPXH1DBD contains multiple signal processors, supporting complex algorithm execution.
Its architecture minimizes noise interference while maintaining deterministic timing across modules.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Series | Mark VI Control System |
| Model | IS200DSPXH1DBD |
| Alternate Identifier | DSPXH1D |
| Product Type | Digital Signal Processor Control Board |
| Primary Function | Real-time signal processing and excitation control |
| PCB Construction | Multi-layer epoxy fiberglass board |
| Layer Configuration | 6-layer high-speed mixed-signal PCB |
| Approximate Dimensions (H × W × D) | 30.5 cm × 19.0 cm × 2.5 cm |
| Weight | Approximately 0.95 kg |
| Mounting Method | Rack-mounted in Mark VI control cabinet |
| Communication Interface | Backplane ISBus connection for deterministic data transfer |
| Connector Type | High-density edge connector |
| Signal Processing Units | Multiple dedicated digital signal processors |
| Power Supply | 5 VDC from backplane logic supply |
| Power Consumption | Approximately 15 W under full operation |
| Energy Storage | Integrated capacitors for voltage stabilization and filtering |
| Noise Mitigation | Onboard filtering and isolation for analog and digital signals |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | –40°C to 85°C |
| Relative Humidity | 5%–95% non-condensing |
| Protective Coating | Conformal coating for industrial reliability |
| Application | Generator excitation, turbine control, and advanced Mark VI algorithms |
FAQ
Q1: Is the IS200DSPXH1DBD brand new and original?
Yes, the IS200DSPXH1DBD we supply is factory-new and 100% original.
Q2: Do you have this board in stock?
Yes, stock is available and ready for dispatch.
Q3: How long does shipping take?
We ship within 3 days to 2 weeks depending on order quantity, typically via DHL.
Q4: What system does this board support?
The IS200DSPXH1DBD supports GE Mark VI turbine and excitation control systems.
Q5: What if the board has quality issues?
We support returns within 30 days if the board has any defects.
