Specification
| Parameter | Specification |
|---|---|
| Module Type | Genius Communications Gateway |
| Model | IC695GCG001 |
| Operating Voltage | 5 VDC ±5% |
| Power Consumption | 2.5 W typical, 3 W max |
| Communication Ports | 1 × Ethernet (10/100 Mbps), 1 × Serial (RS-232/RS-485 selectable) |
| Supported Protocols | Modbus RTU, Modbus ASCII, Modbus TCP/IP, Ethernet/IP |
| Serial Data Rate | Up to 115.2 kbps |
| Ethernet Data Rate | 10/100 Mbps |
| Maximum Devices Supported | Up to 32 devices on serial, multiple TCP/IP clients |
| Input/Output Signals | Status LEDs: Power, Run, Link, Error |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5%–95% non-condensing |
| Isolation | 1500 Vrms between communication ports and logic power |
| Mounting | DIN rail or panel mount |
| Dimensions (L × W × H) | 125 mm × 100 mm × 40 mm |
| Weight | 0.45 kg |
| Certifications / Compliance | CE, UL, RoHS, FCC |
| Diagnostics / Features | Error logging, communication watchdog, configurable retries, status LEDs |
| Environmental Protection | IP20 (enclosure), rugged industrial-grade PCB |
| Firmware Upgrade | Supported via Ethernet or serial port |
FAQ
A1: It supports Genius I/O networks for distributed discrete and analog modules.
Q2: How many Genius I/O modules can be connected per segment?
A2: Up to 64 modules per network segment.
Q3: What is the data update rate for I/O signals?
A3: The module updates I/O data at ≤ 10 ms per scan cycle.
Q4: Can the module be mounted on a DIN rail?
A4: Yes, it supports both 35 mm DIN rail and backplane mounting.
Q5: What is the operating temperature range?
