Specification
| Parameter | Specification |
|---|---|
| Module Type | 5-Slot Expansion Baseplate |
| Model | IC693CHS398 |
| Series Compatibility | GE Series 90-30 PACSystems |
| Number of Slots | 5 |
| Slot Type | Standard Series 90-30 I/O and Communication Modules |
| Mounting Options | DIN rail or panel mount |
| Dimensions (L × W × H) | 254 mm × 76 mm × 31 mm |
| Weight | 0.34 kg |
| Material | Industrial-grade epoxy-coated steel |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity Range | 5%–95% non-condensing |
| Electrical Isolation | Full isolation between slots for safe operation |
| Vibration Resistance | 5–25 Hz: 0.3 mm double amplitude, 25–150 Hz: 2 g |
| Shock Resistance | 15 g, 11 ms half-sine pulse |
| Module Retention | Secured clips ensure modules remain in place during vibration |
| Cable Clearance | Compatible with standard Series 90-30 ribbon and I/O cables |
| Certifications / Compliance | CE, UL recognized, RoHS compliant |
| Applications Supported | Expanding I/O racks, adding control or communication modules |
| Maintenance | Easy access for module replacement without removing entire rack |
| Diagnostics / Indicators | Status LEDs on modules maintain visual verification of proper connections |
FAQ
A1: The baseplate provides five slots for additional Series 90-30 modules.
Q2: Can it be mounted on both DIN rail and panel?
A2: Yes, the baseplate supports both DIN rail and panel mounting for flexibility.
Q3: Is it compatible with all Series 90-30 modules?
A3: It supports most Series 90-30 I/O and communication modules, ensuring seamless integration.
Q4: Does it operate in harsh industrial environments?
A4: Absolutely, it withstands vibration, temperature cycling, and electrical interference.
Q5: Can it simplify system upgrades?
A5: Yes, its modular design allows easy expansion without redesigning existing racks.
