Overview
Specification
| Parameter | Specification |
|---|---|
| Module Type | High-Speed Counter (HSC) |
| Model | IC694APU300 |
| Manufacturer | GE Fanuc / Emerson PACSystems |
| Compatible Systems | RX3i PACSystems |
| Input Signal Types | A, B, C type encoders, TTL/HTL compatible |
| Standard Counting Frequency | Up to 200 kHz |
| Enhanced Mode Frequency | Up to 1 MHz |
| Internal Oscillator | 2 MHz |
| Counting Modes | Up/down counting, quadrature decoding, event counting, pulse accumulation |
| Number of Channels | 4 independent high-speed inputs (depends on configuration) |
| Resolution | 16-bit or 32-bit configurable per channel |
| Power Supply | 5V DC from RX3i backplane |
| Power Consumption | Approx. 2 W |
| Communication Interface | Integrated with RX3i CPU bus |
| Status Indicators | LED indicators for module status, input activity, and error diagnostics |
| Mounting | RX3i backplane slot |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -20°C to 70°C |
| Humidity | 5%–95% non-condensing |
| Shock and Vibration | IEC 60068-2 compliant |
| Safety Standards | CE, UL compliant (depending on region) |
| Configuration | Via PACSystems RX3i programming software (Logic Developer or Proficy Machine Edition) |
| Typical Applications | Motion control, encoder counting, conveyor monitoring, CNC machinery, automated packaging |
FAQ
Q1: Can IC694APU300 handle multiple encoders simultaneously?
A: Yes, it can process multiple A/B/C type encoder inputs concurrently.
Q2: Does this module require CPU intervention for counting?
A: No, the counting operates independently, reducing CPU load and improving efficiency.
Q3: Is it compatible with all RX3i CPUs?
A: It is compatible with most RX3i PACSystems CPUs; check the CPU manual for detailed compatibility.
Q4: What is the maximum enhanced counting frequency?
A: The module supports up to 1 MHz counting with a 2 MHz internal oscillator in enhanced mode.
