Overview
Industrial automation systems require dependable backplane power for predictable performance. Therefore, this power supply ensures consistent voltage regulation across connected modules. Its compact structure also simplifies installation within confined control cabinets.
Specification
| Parameter | Specification |
|---|---|
| Module Type | AC Power Supply Module |
| Platform Compatibility | GE Series 90-30 PLC |
| Input Voltage | 120/240 VAC nominal |
| Input Frequency | 50/60 Hz |
| Input Voltage Range | 85–264 VAC |
| Output Voltage (Backplane) | 5 VDC |
| Output Voltage (Auxiliary) | 24 VDC |
| 5 VDC Output Current | Up to 30 W equivalent capacity |
| 24 VDC Output Current | Approx. 20 W equivalent capacity |
| Overvoltage Protection | Integrated electronic protection |
| Short Circuit Protection | Automatic shutdown and recovery |
| Efficiency | High-efficiency switching design |
| Power Dissipation | Dependent on load conditions |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | –40°C to 85°C |
| Relative Humidity | 5–95% non-condensing |
| Mounting | Direct rack installation |
| Indicators | Power and status LEDs |
| Compliance | Industrial EMC and safety standards |
FAQ
A1: It is designed specifically for GE Series 90-30 PLC systems.
Q2: What input voltage does the module accept?
A2: It accepts 120/240 VAC nominal input within an 85–264 VAC range.
Q3: Does the module provide both 5 VDC and 24 VDC outputs?
A3: Yes, it supplies regulated 5 VDC for the backplane and 24 VDC auxiliary power.
Q4: What protection features are included?
A4: It includes overvoltage and short-circuit protection with automatic recovery capability.
Q5: What is the operating temperature range?
A5: The module operates reliably between 0°C and 60°C.
