Overview
It provides a structured mounting platform for remote I/O modules in distributed automation systems.
Moreover, the baseplate enables efficient signal routing between field devices and the central PLC.Engineers select this remote baseplate when control cabinets require flexible physical separation.
Therefore, it supports scalable layouts across large production floors and processing units.
In addition, the rugged mechanical design ensures long-term stability in industrial environments.
The IC693CHS393 integrates seamlessly with Series 90-30 remote I/O interfaces and communication modules.
As a result, system designers achieve reliable expansion without redesigning the core control platform.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | GE Intelligent Platforms |
| Product Series | Series 90-30 |
| Model Number | IC693CHS393 |
| Module Type | 10-Slot Remote Baseplate |
| Number of Slots | 10 I/O module slots |
| Application | Remote I/O expansion |
| Backplane Bus | Series 90-30 internal backplane architecture |
| Compatible Modules | Series 90-30 I/O and communication modules |
| Mounting Method | Panel-mounted within control cabinet |
| Power Distribution | Provided through compatible power supply module |
| Remote Interface | Works with Series 90-30 remote I/O interface modules |
| Electrical Isolation | Maintains signal integrity across installed modules |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Mechanical Construction | Industrial-grade chassis frame |
| Typical Installation | Remote cabinet or distributed control enclosure |
FAQ
A1: It supports up to ten Series 90-30 I/O or communication modules.Q2: Is this baseplate used for remote installations?
A2: Yes, it is specifically designed for remote I/O expansion applications.
Q3: Does the baseplate include a power supply?
A3: No, it requires a compatible Series 90-30 power supply module.
Q4: Can it operate in industrial temperature ranges?
A4: Yes, it operates reliably between 0°C and 60°C.
Q5: Is the IC693CHS393 compatible with all 90-30 I/O modules?
A5: Yes, it supports standard Series 90-30 I/O and communication modules.
