Overview
It delivers consistent 15-bit resolution, ensuring accurate signal conversion for demanding industrial control environments.
Moreover, the module integrates smoothly into VersaMax and VersaPoint architectures without complex configuration steps.
Engineers select this unit when stable analog measurement directly impacts process efficiency and product quality.
Therefore, it supports both small machine automation systems and large distributed control installations.
The compact housing fits easily into space-constrained control cabinets.
In addition, the modular design simplifies expansion in scalable automation projects.
Specification
| Parameter | Specification |
|---|---|
| Product Model | IC220ALG320 |
| Brand | GE |
| Product Series | VersaMax / VersaPoint Distributed I/O |
| Module Type | Analog Input Module |
| Number of Channels | 4 independent analog input channels |
| Analog Resolution | 15-bit |
| Input Signal Types | Voltage and Current |
| Supported Voltage Ranges | 0–10 V, ±10 V (software configurable) |
| Supported Current Range | 4–20 mA |
| Input Configuration | Single-ended analog inputs |
| Input Impedance (Voltage) | High impedance, suitable for standard transmitters |
| Input Resistance (Current) | Integrated precision shunt for 4–20 mA signals |
| Data Conversion Method | Successive approximation analog-to-digital conversion |
| Conversion Time | Typical fast update suitable for process control loops |
| Accuracy | High linearity with low non-linearity error |
| Isolation | Channel-to-backplane electrical isolation |
| Diagnostics | Per-channel status indication and system diagnostics |
| Status Indicators | LED indicators for module and channel status |
| Backplane Interface | VersaMax / VersaPoint I/O bus |
| Mounting Method | DIN-rail mounting |
| Wiring Connection | Removable terminal block |
| Power Supply | Powered via system backplane |
| Power Consumption | Low internal power draw |
| Operating Temperature | Industrial rated temperature range |
| Storage Temperature | Extended storage temperature range |
| Humidity | Suitable for industrial non-condensing environments |
| Vibration Resistance | Designed for industrial panel environments |
| Protection Features | Overvoltage protection and noise immunity design |
| Typical Applications | Process monitoring, transmitter signal acquisition, PID feedback control |
FAQ
Q1: What types of input signals does the IC220ALG320 support?
A1: The module supports configurable voltage ranges and standard 4–20 mA current inputs.
Q2: How many analog channels are available?
A2: The IC220ALG320 provides four independent analog input channels.
Q3: What resolution does the module provide?
A3: It delivers 15-bit analog resolution for precise industrial measurement applications.
Q4: Is the module compatible with VersaMax systems?
A4: Yes, it integrates directly with VersaMax and VersaPoint distributed I/O platforms.
Q5: Can it operate in industrial environments with electrical noise?
A5: Yes, built-in isolation and robust design ensure reliable operation in harsh environments.
